NATURCLAD-W - Cladding

Name: NATURCLAD-W - Cladding
Brand: Parklex Prodema
SKU: t2HkT17Y9Y8vZFnKwYv44R

Verified by manufacturer 6 months ago

Parklex Prodema

Third party certifications:

PEFC
Certificate type
VOC Content test Certificate
Certificate type
BS EN 13501-1
Certificate type
EPD
Certificate type

Maintenance free natural wood veneer cladding and facades.

Jump to:

+34 9438 07000 Website

Application

HPL cladding panels that can be installed as a ventilated facades on full size panles, cut to size or by way slats, on false ceilings and on curved walls.

They are suitable for:

Residential purpose buildings under 11m.
Assembly and recreation buildings.
Any other building.

Description

NATURCLAD-W is a laminated wood board for exterior cladding and facades that requires zero maintenance. The panels combine the virtues of wood, its natural warmth and beauty, with technical requirements to ensure optimum performance on exteriors over time. They are composed of a high-density bakelite body, treated wood veneer based on synthetic resins on the surface and an outer film that provides greater durability to the panels and protects them from solar radiation, atmospheric agents and dirt.

The PEFC certification seal guarantees that our wood boards have been made with raw materials of forest origin managed in a socially and environmentally responsible way.

Features and benefits:

0.6 mm thick natural wood surface layer.
6–22 mm thickness.
Maintenance-free HPL panels.
PEFC-certified raw material.
Resistance to extreme atmospheric agents.
UV-ray resistant tone.
Fire rate according to Euroclass EN 13.501-1: C-s1,d0 or B-s1,d0.
Complete installation system.
On-demand project assistance service.
Highly resistant to extreme atmospheric agents such as sunlight and pollution.
Anti-graffiti properties.
10-year warranty.

Colour, pattern and surface finish (EN 438-8):

Due to the fact that wood is a natural product, each veneer may be considered as unique.
Colour and structure differences are considered as normal. Singularities such as knots and resin inclusions are not considered as defects, but as a part of the décor.
There are differences in light fastness performances depending on the wood species and the source of the wood.

General information

Color	Other Bronze Copper Gold Silver White Brown Red Show more
Finish	Smooth Matt
Material	High pressure laminate (HPL) Wood Timber
Shape	Rectangle
Length	Bespoke 2440 mm 2700 mm
Width	1220 mm
Height	6 mm 8 mm 10 mm 12 mm 14 mm 18 mm 20 mm 22 mm Show more Manufacturer guidance Thickness.
Warranty description	Ten year

Uniclass	Pr_25_71_94_37 High-pressure decorative laminates (HPL or HPDL)Primary
CAWS	K13/160 Proprietary H20/10 Sheet cladding H20/155 Sheet cladding (attached to timber battens) P20/30 Proprietary P20/170 Proprietary H21/15 Horizontal timber weatherboarding H21/10 Vertical timber weatherboarding K13/160 Proprietary H21/116 Horizontal timber weatherboarding H21/115 Vertical timber weatherboarding H21/111 Horizontal timber weatherboarding H21/110 Vertical timber weatherboarding

Specification data - High-pressure decorative laminates (HPL or HPDL)

Standard	To BS EN 438.
Reaction to fire	To BS EN 13501-1, C-s1,d0. To BS EN 13501-1, B-s1,d0.
Thickness	6 mm. 8 mm. 10 mm. 12 mm. 14 mm. 16 mm. 18 mm. 20 mm. 22 mm.
Finish	- Manufacturer guidance Consult manufacturer for details.
Pattern	Smooth. Matt. Manufacturer guidance Consult manufacturer for details.
Colour	Rustik. Hazel. Chestnut. Hazel Matte. Rustik Matte. Coffee. Boreal. Cocoa. Quartz. Antra. Nux. Rubi. Onix. Ambar. Pale. Silver.

Dimensional stability	To EN 438-2, ≤0.3 (% maximum longrain); ≤0.6 (% maximum crossgrain). Manufacturer guidance Dimensional stability at elevated temperature - cumulative dimensional change.
Impact resistance	To EN 438-2, ≥1.800 mm. Guidance for specification option: Maximum height for which no visible surface cracking or imprint greater than 10 mm. Manufacturer guidance Resistance to impact by large diameter ball.
UV resistance	To EN 438-2, ≤3 grey scale rating (contrast); ≤4 rating (aspect). Manufacturer guidance Resistance to UV light.
Weathering	To EN 438-2, ≤3 grey scale rating (contrast); ≤4 rating (aspect). Manufacturer guidance Resistance to artificial weathering. (Irradiance total 325 MJ/m²)(2).
Water vapour permeability	To EN 438-7, 110 μ (wet cup method); 250 μ (dry cup method).
Resistance to fixings	To EN 438-7, 2000 N (screw holding value t ≥6 mm), 3000 N (screw holding value t ≥8 mm); 4000 N (screw holding value t ≥10 mm).
Flexural strength to EN ISO 178	≥80 MPa (longrain and crossgrain).
Flexural Modulus	To EN ISO 178, ≥9.000 MPa (longrain and crossgrain).
Thermal resistance to EN 12524	≤0.3 W/m K.
Thermal conductivity (to EN 12524)	≤0.3 W/m K.
Density	To EN ISO 1.183, ≥1.35 g/cm³.
Third-party certification	PEFC Certified.

Sustainability data

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	Spain
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	19.7 kg CO₂ eq/m²
Recyclability	Recyclability is possible, but the reuse of the reuse of the material would be the main recommendation. Please contact the manufacturer for recyclabulity options.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	12 %
