Application

Sliding patio doors.

Description

A range of unplasticized polyvinyl chloride (PVC-U) sliding patio doors, available in a range of styles in three standard finishes.


Features and benefits:

  • Contemporary, high performance sliding door system.
  • Operates silently, securely and effortlessly on high quality nylon rollers.
  • Spans up to 6 m (three panes).
  • Suitable for very wide openings and for homeowners looking to make the most of great views and their indoor/ outdoor living space.
  • Excellent weather performance.
  • Fully reinforced PVC-U profile.
  • Six position multi-point locking mechanism.
  • Complementary hardware.
  • Contemporary colour range from stock.

General information

Shape

Rectangle

Color

White

Other

Guidance for specification option:

Bespoke, consult manufacturer.

Finish

PVC-U

Material

Glass

PVC-U

Warranty description

Ten year

Size

Guidance for specification option:

Bespoke:

Two panes: up to 4500 mm-wide x 2500 mm-high.

Three panes: up to 6000 mm-wide x 2500 mm-high.

Four panes: up to 6000 mm-wide x 2500 mm high.

Uniclass

Pr_30_59_24_80 Sliding door and partition setsPrimary

CAWS

L20/520 Sliding doors

Specification data - Sliding door and partition sets

Performance

External.

Arrangement

Two pane slider: XO.

Two pane slider: OX.

Three pane slider: OXO.

Three pane slider: XOO.

Three pane slider: OOX.

Four pane slider: XOOX.

Four pane slider: OXXO.

Manufacturer guidance

'O' denotes fixed panel; 'X' denotes sliding, when viewed from outside.

Door leaves

-

Construction

Manufacturer's standard.

Guidance for specification option:

Glazing beads: as drawing.

Manufacturer guidance

Fully welded construction.

Finish and colour

RAL 9016 Traffic White.

Decoroc patented coating system. Colour RAL.

Guidance for specification option:

Insert requirements,

Wood grain foil laminate.

Guidance for specification option:

Insert requirements,

Operation

Manual.

Hardware

Full depth euro-groove. High security six point lock.

Accessories

Not required.

Mechanically jointed frame.

Guidance for specification option:

Consult manufacturer for details.

Glazing

Guidance for specification option:

Insert requirements; accepts units from 5 mm up to 42 mm thick.

Ventilation

Not required.

Proprietary ventilation device.

Guidance for specification option:

Insert requirement. Proprietary ventilation devices can be fitted to the doors in compliance with building regulations.

Weathering trims

Not required.

3303.

Guidance for specification option:

Head drip.
