Moduleo 55 Tiles offers 52 stone looks in different formats for the ultimate design flexibility and creative transitions.

Jump to:
+44 (0)1332 851500 www.ivc-commercial.com

Application

Suitable for internal flooring, including commercial use.

Description

Moduleo 55 Tiles offers 52 stone looks in different formats for the ultimate design flexibility and creative transitions.


Features and benefits:

  • Luxury vinyl tiles (LVT) and planks flooring available in 52 stone effect designs in different formats. High dimensional stability and a 0.55 mm-thick scratch, stain, wear and water-resistant layer, suitable for medium to high commercial traffic.
  • Format: Tile.
  • Dryback and Click options available.
  • Wear layer polyurethane (PUR) treatment: Protectonite.
  • Suitable for underfloor heating.
  • Ten-year warranty.
  • CE marked.
  • Indoor air quality rating: A+.
  • Acoustic insulation: Dryback - 3 dB; Click - 4 dB.
  • Acoustic insulation with underlay: Dryback - 10 dB; Click - 13dBB.
  • Total weight: Dryback 4059 g/m²; Click - 7691 g/m².
  • Wear Layer: 0.55 mm.
  • Curling: ≤2 mm.
  • Dimensional stability: ≤0.05%.
  • Electrical resistance: ≤109 Ohm.
  • Electrostatic performance: <2 kV.
  • Indoor emission rating: A+.
  • Level of use: 23–32–42.
  • Light fastness: ≥6.
  • Residual indentation: ≤0.10 mm.
  • Scratch resistance: Class T.
  • Castor chair: No damage.
  • Slip resistance: R10.
  • Thermal resistance: 0.01 m²K/W.
  • Fire rating (to EN 13501): Bfl-s1.
  • Wear layer polyurethane (PUR) treatment: Protectonite.

General information

Finish

Embossed

Color

Beige

Brown

Grey

Black

Pink

Show more

Material

Vinyl

Shape

Rectangular

Square

Size

329 x 659 x 2.5 mm

Azuriet / Brushed metal / Concrete / Desert Crayola / Jura Stone / Riverwood / Steel Rock

493 x 493 x 2.5 mm

Mysto only

609.6 x 609.6 x 2.5 mm

Ceppo and Cloud Stone only

WarrantyDescription

Ten-years

Uniclass 2015

Pr_35_57_71_62 Particle-based enhanced slip-resistant polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Specification data - Particle-based enhanced slip-resistant polyvinyl chloride (PVC) tiles Enhanced data

Standard

To EN ISO 10874.

Use class

To BS EN ISO 10874, class 23 / To BS EN ISO 10874, class 33 / To BS EN ISO 10874, class 42.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Recycled content

50%.

Size

329 x 659 mm.

Azuriet / Brushed metal / Concrete / Desert Crayola / Jura Stone / Riverwood / Steel Rock

493 x 493 mm.

Mysto only

609.6 x 609.6 mm.

Ceppo and Cloud Stone only

Thickness

2.5 mm.

Colour and pattern

Azuriet 46148.

Azuriet 46860.

Azuriet 46919.

Azuriet 46939.

Azuriet 46959.

Azuriet 46985.

Brushed Metal 20830.

Brushed Metal 20950.

Ceppo 46151.

Ceppo 46921.

Ceppo 46961.

Cloud Stone 46134.

Cloud Stone 46244.

Cloud Stone 46854.

Concrete 40876.

Concrete 40945.

Concrete 40986.

Desert Crayola 46454.

Desert Crayola 46533.

Desert Crayola 46562.

Desert Crayola 46616.

Desert Crayola 46696.

Desert Crayola 46772.

Jura Stone 46110.

Jura Stone 46191.

Jura Stone 46214.

Jura Stone 46820.

Jura Stone 46956.

Jura Stone 46960.

Jura Stone 46975.

Jura Stone 46935.

Mysto 46164.

Mysto 46921.

Mysto 46946.

River Wood 46137.

River Wood 46882.

River Wood 46993.

Steel Rock 46234.

Steel Rock 46832.

Steel Rock 46940.

Product Reference

Moduleo 55 Tiles - Luxury Vinyl Tiles - Dryback

Moduleo 55 Tiles - Luxury Vinyl Tiles - Click

Format

Click.

Dryback.

Environmental information

Country of material origin

Belgium

Country of product manufacture

Belgium

Recyclability

100%

Recycled content

50

Digital objects

Platform Compatible Version Certified to
Revit

Revit 2017

1

2.0
IFC
-

1

2.0
Download now from NBS National BIM Library

Case studies

Third party certifications

  • Certified by SCS Global Services: Certificate: floorscore
