Moduleo 55 Expressive - Vinyl tiles

Moduleo 55 Expressive - Vinyl tiles

IVC Commercial Variant:

Moduleo 55 Expressive is a vinyl tile, which combines dimensional stability, in a range of designs, with scratch, stain, wear and water-resistance.

Jump to:
+44 (0)1332 851500 www.ivc-commercial.com

Application

Suitable for commercial flooring, with a variety of layouts possible.

Description

Luxury vinyl tile (LVT) flooring available in 12 designs which range from natural to abstract, from authentic reproductions to original creations.


Features and benefits:

  • With high dimensional stability and a 0.55 mm thick scratch, stain, wear and water-resistant layer, suitable for medium to high commercial traffic. The collection offers a range of designs that can be cut precisely to the final plank or tile size, creating complex layouts with the ability to combine random puzzle patterns and designs.
  • Format: Plank/ tile.
  • Wear layer polyurethane (PUR) treatment: Protectonite.
  • Suitable for underfloor heating.
  • Ten-year warranty.
  • CE marked.
  • Indoor air quality rating: A+.
  • Acoustic insulation: 3 dB.
  • Acoustic insulation with underlay: 10 dB.
  • Total weight: 4059 g/m².
  • Wear layer: 0.55 mm.
  • Curling: ≤2 mm.
  • Dimensional stability: ≤0.05%.
  • Electrical resistance: ≤109 Ohm.
  • Electrostatic performance: <2 kV.
  • Indoor emission rating: A+.
  • Level of use: 23–32–42.
  • Light fastness: ≥6.
  • Residual indentation: ≤0.03 mm.
  • Scratch resistance: Class T.
  • Castor chair: No damage.
  • Slip resistance: R9, R10.
  • Thermal resistance: 0.01 m²K/W.
  • Fire rating (to EN 13501): Bfl-s1.
  • Wear layer polyurethane (PUR) treatment: HyperGuard+.

General information

Finish

Embossed

Color

Brown

Grey

White

Black

Material

PVC

Shape

Rectangular

Square

Size

196 x 1320 mm

246 x 1498 mm

493 x 493 mm

WarrantyDescription

Ten-years

Uniclass 2015

Pr_35_57_71_62 Particle-based enhanced slip-resistant polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Specification data - Particle-based enhanced slip-resistant polyvinyl chloride (PVC) tiles Enhanced data

Standard

To EN ISO 10874.

Use class

To BS EN ISO 10874, class 23 / To BS EN ISO 10874, class 33 / To BS EN ISO 10874, class 42.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Recycled content

50%.

Size

196 x 1320 mm.

191 x 1316 mm.

1580 x 6320 mm.

Thickness

2.5 mm.

Colour and pattern

Jumble Stone 46140.

Product Reference

Moduleo 55 Expressive - Luxury Vinyl Tiles - Dryback

Moduleo 55 Expressive - Luxury Vinyl Tiles - Click

Environmental information

Country of material origin

Belgium

Country of product manufacture

Belgium

Recyclability

100%

Recycled content

50

Digital objects

Platform Compatible Version Certified to
Revit

Revit 2017

1

2.0
IFC
-

1

2.0
