Modular High Security Deadlock 9788
Application

Locks for entrance doors, corridor and other swing doors with door pulls and push plates. Also as a secondary lock on any door.

Description

Application:

Locks for entrance doors, corridor and other swing doors with door pulls and push plates. Also as a secondary lock on any door.

Features:

  • Available with backset 50 or 70 mm.
  • Hardened steel deadbolt thrown 21 mm by 90° turn of key or thumbturn.
  • Available with a built-in microswitch.
  • Supplied with striking plate.

Function:

The deadbolt is operated by a 360° turn of the key or thumbturn.

Suitable cylinders:

Scandinavian oval or round:

  • ASSA 5-Pin.
  • ASSA Flexcore Plus.
  • ASSA 4800.
  • ASSA Twin Combi.
  • ASSA dp4400.
  • ASSA CLIQ.

Additional information for this product is available from:

http://www.assa.co.uk/en/site/assacouk/Products1/?groupId=644173

General information

Features

Available with backset 50 or 70 mm

Hardened steel deadbolt thrown 21 mm by 90° turn of key or thumbturn

Available with a built-in microswitch

Supplied with striking plate

Uniclass 2015

Pr_30_36_08_24 Door latches

Primary

CAWS

P21/24 Door locks

P21/515 Door locks

Specification data - Door latches

Product Reference

Modular Dead Lock 2788, Double Cylinders

Modular Dead Lock 2788, Single Cylinder

Modular Dead Lock 2788, Single Cylinder And Thumbturn

Backset

50 mm

70 mm

Colour/ Finish

Bright zinc

Special finish.

Polished brass

Satin chrome

Microswitch

Not required

Required
