Verified by manufacturer 1 day ago
Contour Board - Antique Oak 196 mm
Composite deck boards with curved line patterns.
Suitable for use externally in decking applications such as:
Installation:
Subframe requirements are based on normal 300 mm or 400 mm joist centres. Different patterns are created without the need for complicated subframe configurations.
Modello by Millboard is a composite decking board featuring a modern aesthetic using curved line patterns that can be arranged into different designs.
The curve pattern is suitable in zonal areas, feature inlays, or as a centrepiece for a full deck.
Features and benefits:
Color | Beige Black Brown Grey Ivory |
Finish | Textured |
Material | Composite |
Shape | Rectangle |
Length | 3600 mm |
Width | 196 mm |
Height | 32 mm |
Warranty description | Ten year Guidance for specification option: Ten year limited structural decking warranty (anything other than residential). 25 year Guidance for specification option: 25 Year limited structural decking warranty (residential only). |
Uniclass | |
CAWS | Q55/380 Deck boards Q55/110 Deck |
SKU Code | MDMC196A |
Profile | Plain. |
Finished size | |
Section | 196 x 32 mm. |
Length | 3.6 m. |
Fixings | Millboard Durafix® stainless steel decking screws 4.5 x 45 mm. Guidance for specification option: For fastening decking onto Plas-Pro or DuoSpan joists. Millboard Durafix® stainless steel decking screws 4.5 x 60 mm. Guidance for specification option: For fastening decking onto timber joists. |
Accessories | Not required. Fascia board. Guidance for specification option: 3600 x 146 x 16 mm. Available in the same colour range. Consult manufacturer and insert requirements for colour of fascia or specify separately. Enhanced grain boards. Guidance for specification option: Available in 3600 x 176 x 32 mm and 3600 x 126 x 32 mm boards. Available in the same colour range (except 126 mm is not available in the colour 'Jarrah'). Consult manufacturer and insert requirements or specify separately. |
Weight | 18 kg/m². |
Coverage | 1.39 boards/m². |
Colour | Antique oak. |
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Manufacturing plant location | |
Material | Composite |
Recyclability | Manufacturer guidanceNot currently recycled but upcycled and used as path edging, planters, seating and other outdoor creations. Municipal incineration of Millboard provides effective energy recovery. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 38 % |
Expected Life | 30 year |
