Back-to-wall washdown WC suite with concealed cistern.
Back-to-wall washdown WC suite with concealed cistern. Designed for domestic, hotel, leisure, education and commercial applications.
N13/10 WC pans and flushing arrangements
N13/300 WCs and cisterns
MD1438WH - Moda BTW WC
Seat and cover
MD7815WH - Bottom fix stainless steel hinge
MD7851WH - Soft closing mechanism
WF1240WH - P trap
WF1241WH - S or turned P trap
Concealed cistern, dual flush, lever, SSIO, 6/4L, chrome plated lever up to 114 mm duct, with delayed action inlet valve.
Spatula lever for 114 mm wall depth.
Chrome plated extended duct lever handle. For wall thicknesses up to 340 mm.
Lever handle, chrome plated. For wall thicknesses up to 225 mm.
Air button, dual flush, small button, chrome plated. For 3-40 mm panel depth.
Air button, dual flush, plastic large plate 150 x 230 mm chrome plated. Minimum 75 mm panel depth.
Air button, dual flush, mini plate 80 x 124 mm chrome plated. Minimum 65 mm panel depth.
Standard product features
WC screwed to floor with fixings provided. Sealed to wall and floor using silicone building sealant.
