Moisture resistant MDF panel for use in humid conditions.
A moisture resistant MDF panel designed for use in humid conditions in accordance with MDF.H (option 1) as defined in BS EN 622- 5. MEDITE MR is distinguishable from other MEDITE MDF products by its green identification colour.
Features and benefits:
Find out more here: https://youtu.be/WznlWs3fFWU
Finish | Smooth  |
Material | Wood Guidance for specification option: Medium-density fibreboard.  |
Shape | Rectangle  |
Length | 2440 mm 3050 mm  |
Width | 1220 mm  |
Uniclass | |
CAWS | K11/875 Medium-density fibreboard N10/10 Purpose-made N10/110 Purpose-made P20/200 Medium-density fibreboard  |
Product range |
Classification data | |
Standard | BS EN 13986.  |
Grade | To BS EN 622-5, type MDF.H.  |
Sheet size | 1220 x 2440 mm. 1220 x 3050 mm. 1525 x 3050 mm. 1830 x 2440 mm.  |
Thickness | 6 mm. 9 mm. 12 mm. 15 mm. 18 mm. 25 mm. 30 mm. Manufacturer guidanceOther thicknesses are available by special request.  |
Edges | Square.  |
Formaldehyde class | To BS EN 622-1, Class E1.  |
MoistureContent | 7% ±2% at the time of manufacture.  |
Country of material origin | Ireland  |
Country of product manufacture | Ireland  |
Material | Wood Guidance for specification option: Medium-density fibreboard.  |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
Revit 2017  | 1  | |
| - | 1  |
