MB-DPA Automatic Sliding Door
Description

An automatic sliding door, which is designed for use as an individual construction in larger glazing modules and as part of aluminium curtain wall. It can employ both thermally insulated (MB-59S) and non-insulated (MB-45) aluminium profiles. Utilizes large-size glass panels, allowing for a great amount of light to enter into the interior, while the parallel opening of the sliding leaf offers space-saving and great functionality. Silent and easy to operate, and can adapt to the majority of conditions.

Can be used in conjunction with MB-45, MB-59S, MB-60, MB-70 and MB-86 profiles for fixed screens.

General information

Uniclass 2015

Pr_30_59_24_80 Sliding door and partition setsPrimary

CAWS

L20/520 Sliding doors

Specification data - Sliding door and partition sets Enhanced data

Product Reference

MB-DPA Automatic Sliding Door

Profile

MB-45

Non-thermally broken.

MB-59S

Thermally broken.

Door leaf

-

Glazing/ infill details

Thickness: 4.5–60 mm available.

Standard product features

Technical characteristics:

  • Depth of frame: 50–70 mm.
  • Depth of leaf: 45–50 mm.
  • Leaf visible width 'T' profile: 69–73.5 mm (minimum).
  • Size of door (width): 1500 mm (maximum).
  • Weight of leaf: 200 kg (maximum).
