Marble Resin Bound Permeable Paving - marble

Verified by manufacturer 1 month ago

SureSet Resin Systems Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

A resin bound surface course consisting of imported crushed and rounded marble.

Jump to:
BIM object icon
+44 (0)1985 841180 Website

Application

  • Access roads and car parks.
  • Creative applications including logos.
  • DIY and trade projects.
  • Driveways and housing access.
  • Step treads and bridges.
  • Heritage or leisure locations.
  • Hard landscape area; pathways, pond surrounds and garden patios.
  • Pool surrounds.
  • Public and private walkways.
  • School grounds.
  • Town centres.
  • Tree pits.

Description

SureSet is a resin bound surface course, available with various sizes of imported crushed marble particles, fully coated with a three-part chemically curing resin, combined in a forced action mixer. The resin is UV-stable, flexible and clear in colour. SureSet is installed to a seamless finish.


Features and benefits:

  • Available in a wide range of colours.
  • Choice of crushed or rounded particles.
  • Durable, UV stable, sustainable urban drainage system (SuDS) and crack resistant.
  • Highly permeable mixes are available for tree pits, communal areas, poolsides and many other applications.
  • Accessible, multi-layer surface.
  • Because the finish is smooth there is no loose stone – guaranteed.
  • SureSet can be designed to withstand heavy loads.
  • Rounded aggregates should be avoided on sloping ground, to minimise slipping.
  • Special mixes can be tailored to suit most conditions and specifications.
  • Installation: SureSet UK Limited maintains full control over all installations, either with direct labour or with approved contractors working under guidance.
  • Application is a low energy cold applied process.
  • A low-emission system, using only non-volatile components.
  • Average curing time for pedestrian traffic: 6–12 hours.
  • Average curing time for vehicular traffic: 14–24 hours.
  • SureSet can be laid in temperatures as low as 0ºC and is unaffected by light rain and damp surfaces.
  • Suitable surfaces include asphalt, smooth concrete, SureCell structure or crushed stone for tree pits.
  • DIY kits available providing 1 m² coverage at 16 mm depth.
  • Trade and DIY Packs are available for larger self install projects.


General information

Color

White

Black

Grey

Beige

Green

Finish

Smooth

Material

Marble

Sourced from quarries in Spain and Italy.

Polyurethane

Resin

Granite

Stone

Shape

Rounded and crushed.

Circle

Triangle

Square

Length

Bespoke

Width

Bespoke

Height

Bespoke

WarrantyDescription

20 year

SureSet resin bound aggregate surfacing is fully guaranteed, subject to conditions, for 21 years from the date of application against:


  • Loose stone.
  • Cracking.
  • Oil damage.
  • ultraviolet degradation.
  • Colour change.
  • Frost damage.
  • Poor quality workmanship.


Uniclass

Pr_35_31_05_71 Resin-bound mixed aggregate surfacingsPrimary

CAWS

Q23/225 Proprietary resin bound chippings

Q23/226 Proprietary resin bound chippings overlay

Specification data - Resin-bound mixed aggregate surfacings

Aggregate

-

Type

Marble.

Size (nominal)

3 mm.

6 mm.

10 mm.

Colour

Blush.

Rounded only.

Buttermilk.

Diesel.

Rounded only.

Popcorn.

Safari.

Crushed only.

Astro peake.

Forest green.

Crushed only.

Sterling forest.

Crushed only.

Winter frost.

Starlight

Binder

-

Type

Polyurethane resin.

Colour

Clear.

Profile

Crushed.

Rounded.

Depth

Application depth:

- Rural pathway and private driveway:

  • Marble size: 3–16 mm depth of SureSet.
  • Marble size: 6–18 mm depth of SureSet.
  • Marble size: 10– 24 mm depth of SureSet.


- Tree pit:

  • Marble size: 10–40 mm depth of SureSet.


- Car parks:

  • Marble size: 3–18 mm depth of SureSet.
  • Marble size: 6–20 mm depth of SureSet.
  • Marble size: 10–26 mm depth of SureSet.


12 mm.

16 mm.

18 mm.

22 mm.

24 mm.

Show more

Environmental information

Country of material origin

Spain

Marble also sourced fom Italian quarries.

Country of product manufacture

United Kingdom

Recyclability

Yes

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
IFC
-

5

Revit

Revit 2017

5

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

BBA Agrement 20/5719

Literature

SureSet Brochure

SureSet Brochure
