8" Link & Lock Batten - Batten and fin application

Verified by manufacturer 3 months ago

Longboard Products Third party certifications:
  • EPD

    EPD

    Certificate type

  • UKAS

    UKAS

    Certificate type

  • Declare

    Declare

    Certificate type

Two-piece 1 5/8 x 8" aluminium battens with concealed fastener system.

Jump to:
+44 2039911138 Website

Application

Suitable for use as ceiling battens, wall features and façade cladding externally and internally.

Description

Link & Lock™ is the innovative hidden fastener solution! The system was designed for easy install and creative adaptability in a variety of interior and exterior applications.


The Link & Lock™ aluminum batten system complement any architectural design being non-combustible, VOC free and corrosion resistant and also accepts matching Longboard end caps where needed to create a premium finished look.


The system is available in various dimensions and all woodgrain, solid color, naturally aged metal, and specialty finish options. These 2-piece battens can be installed in a variety of different ways and orientations to achieve beam, fin or louver designs.



Features and benefits:

  • Built for easy installation and creative adaptability.
  • Available in woodgrain, solid and shimmer colour options. Custom colours are also available.
  • 15 year warranty. 20 year ultra-warranty available for additional cost; consult manufacturer for details.
  • VOC-free.
  • Non-combustible.
  • Weather resistant.
  • Accepts matching Longboard end caps where required, to create a finished look.

General information

Color

Black

Blue

Bronze

Brown

Grey

Show more

Finish

As per manufacturer and includes:

  • Woodgrain.
  • Solid.
  • Shimmer.

Gloss

Powder-coated

Material

Aluminium

Alloy 6063-T5.

Shape

Rectangle

Length

7315.2 mm

Width

203.2 mm

Height

41.28 mm

Warranty description

15 year

20 year

Ultra-warranty available for additional cost; consult manufacturer for details.

50 year

Uniclass

Pr_25_71_51_06 Aluminium traditional sheetsPrimary

CAWS

H72/130 Aluminium sheet fully supported wall covering

Product range

Two Piece Link and Lock Batten

Specification data - Aluminium traditional sheets

Factory finishes

Powder coated.

Thickness

Base metal thickness.

0.062 mm.

Colour

Custom colours are available; consult manufacturer for more information.

Anodic ice.

Birchwood.

Biscotti.

Black.

Bone white.

Show more

Accessories

Not required.

Beam end cap.

Beam spline connection top.

Ceiling beam hanger.

Hanger bracket.

Profile

41.28 x 203.2 mm.

1 5/8 x 8".

Length

7315.2 mm.

24 ft.

Material

Aluminium alloy 6063-T5.

Gloss level

30 (±5).

Fixing

The first L-piece is fastened directly to the supporting structure and then the second L-piece is snapped in place. Consult manufacturer for more information.

Sustainability data

Contains Red List materials

No

Country of material origin

Canada

Country of product manufacture

Canada

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

6.75 kg CO₂ eq/kg

Recyclability

100%

Recycled content

50 %

EPD

BIM objects

Platform Compatible Version
Revit
-

1

Third party certifications

EPD

EPD

Environmental Product Declaration

UKAS

UKAS

UK Fire Testing

Declare

Declare

Longboard Declare Label
