Liquasil Ultra PU Waterproofing System

Liquasil Ultra PU Waterproofing System

Liquasil Ltd Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Reinforced polyurethane (PU) flat roof waterproofing system for flat and pitched roofs.

Jump to:
+44 (0)1217 095352 www.liquasil.com

Application

Suitable for seamless installation onto both old and new flat and pitched roof installations. Compatible with most timber insulated composite decks, concrete and asphalt substrates. Can be extended up and over brick/ concrete parapet walls if required.

Description

Reinforced polyurethane (PU) flat roof waterproofing system for flat and pitched roofs.


Features and benefits:




  • The embedment and protective coats can be applied by hand using sacrificial brushes and rollers.
  • The mat is highly flexible: Easy to cut, mould and lay with no spring back (even on sharp angles), and has a fast and consistent wet-out speed for rollering of liquid waterproofing components. No fibre wicking will occur.
  • Short curing times allow the product to be quickly over-coated.
  • Highly waterproof.
  • 15, 20 or 25 year waterproofing warranty as standard (depending on film weight of UV coat).
  • 12 year Insurance-Backed or full single-point Latent Defects Insurance Guarantees available at extra cost via installer.
  • BBA certified.

Components (in order of application):




  • Liquasil Ultra PU Embedment Coat: One-component, moisture triggered elastomeric urethane coating, specifically developed to be the first/ embedment coat of a waterproofing membrane for use on roof surfaces. Applied via brush, roller or powered roller.
  • Liquasil Ultra Chopped Strand Reinforcement Mat: Emulsion coated system reinforcement. To be rolled into the embedment coat. Will dissolve after approximately two minutes, allowing free-forming of the mat around to facilitate ease of installation around details.
  • Liquasil Ultra PU UV Coat: One-component, moisture triggered elastomeric urethane coating, specifically developed to be the second, protective coat of a waterproofing membrane for use on roof surfaces.
  • Applied via brush, roller or powered roller.


Surface preparation:



  • Surfaces must be clean, dust-free and dry before application.
  • All chippings, dirt, soil, and fungal growth must be removed from the surface prior to installation, through either power washing or fungicidal wash.
  • Remove any defective coating back to a firm edge.
  • All wood, wood based materials and mortar are to be primed with Liquasil Ultra Primer. Metal surfaces should be primed with Liquasil SWT Corrosion Primer.

Where slip resistant walkways are required, this can be achieved by the application of an extra coat of Liquasil Ultra PU Top Coat incorporating an aggregate.

See manufacturer's literature for further details on installation and surface preparation techniques.

General information

Finish

Waterproof.

Color

Mid-grey or charcoal grey

Material

Manufacturer's standard.

  • Liquasil Ultra PU Embedment Coat: One-component, moisture triggered elastomeric urethane coating
  • Liquasil Ultra Chopped Strand Reinforcement Mat: Emulsion coated system reinforcement
  • Liquasil Ultra PU UV Coat: One-component, moisture triggered elastomeric urethane coating. High volume solids content and UV stable system.

Shape

Formless (liquid).

WarrantyDescription

 15–25 years.

Consult manufacturer for details.

Uniclass 2015

Pr_35_31_68_64 Polyurethane (PUR) waterproof coatingsPrimary

CAWS

J31/10 Warm deck roof coating

J31/110 Cold deck roof coating

J31/120 Warm deck roof coating

J31/130 Inverted roof coating

J31/5 Cold deck roof coating

Specification data - Polyurethane (PUR) waterproof coatings Enhanced data

Third party certification

BBA Certificate 18/5571.

Colour

Mid-grey

Charcoal grey

Environmental information

Country of product manufacture

United Kingdom
