LimePath EasiWalk UV System

Application

Suitable for footpaths where there are access limitations for alternative sub-bases.

Description

A ‘no-dig/ no-binder' SuDS-compliant system that provides an ultraviolet-stable permeable system suitable for footpaths where there are access limitations for alternative sub-bases. The aggregate blends have been designed to achieve strength, resilience, porosity and decoration.


Features and benefits:

  • UV-stable; will not discolour nor degrade.
  • Tested to slip-resistant BS 8204-6.
  • SuDS-compliant permeable paving: 850 L/m²/minute.
  • Natural and recycled aggregate available.
  • 25 mm depth installation onto an existing concrete base.
  • 35/ 40 mm depth installation, directly onto type 1 or 3.
  • All aggregates selected to reduce the chances of rust appearing.
  • Foot traffic after 14–15 hours at 20°C.
  • LimePath EasiWalk UV is a specialist product, and must only be applied by specialist applicators.
  • Manufactured UKAS ISO 9001 in line with the guidance notes published by the Resin Bound Technical Committee as part of FeRFA: the Resin Flooring Association.

General information

Color

Various. See manufacturer mix blend sheets.

Material

Resin and aggregate

Uniclass 2015

Ss_30_14_02_71 Resin-bound aggregate light-duty paving systemsPrimary

CAWS

Q23/225 Proprietary resin bound chippings

Specification data - Resin-bound aggregate light-duty paving systems Enhanced data

Geotextile below granular sub-base

Required.

Not required.

Granular sub-base

175 mm minimum well-compacted type 3 granular sub-base or similar approved – SuDS-compliant (no binder course)

Surface course

LimePath, 40 mm minimum depth.

Edge restraints

Required.

Product Reference

LimePath EasiWalk UV System

Impermeable membrane

Required.

Not required.

Thickness:

25 mm.

35 mm.

45 mm.

Aggregate

Dior 10 mm.

Espresso 10 mm.

Honey gold 10 mm.

Honey pebble 10 mm.

Marscape 10 mm.

Show more

Environmental information

Country of material origin

United Kingdom

Third party certifications

  • FeRFA: UKAS ISO9001
