Verified by manufacturer 2 months ago
4 mm Single Low E Tough - 0.3 mm vacuum cavity - 4 mm Clear Tough
EPD
Certificate type
Toughened low sightline 8.3 mm, 10.3 mm or 12.3 mm thick vacuum glazing unit with a U-value of 0.4 W/m²K.
For reglazing of existing windows in Listed properties or those in conservation areas to vastly improve energy efficiency and sound attenuation. Also for installing in new windows and new sashes for existing windows to deliver high performance windows in heritage applications.
Durable and energy-efficient vacuum glazing units, combining modern performance with an 8 mm profile for architects and specifiers working on listed properties or those in conservation areas.
Features and benefits:
Guarantees:
LandVac Enhance Vacuum Glazing Units:
LandVac Enhance glazing is a suitable solution for retrofit of heritage glazing in listed properties and buildings located in conservation areas as it eliminates the double reflection that makes standard double glazing unsuitable. This feature also addresses planning permission issues that arise from this visual disturbance.
Compared to slim double glazing, LandVac heritage glazing is significantly thinner and longer lasting, making it easier to install and maintain. Additionally, it has high insulating properties, resulting in significant energy savings and a reduction in carbon emissions. This product is an excellent choice for retrofitting projects where it's plugless design and low sightline fit existing rebates, allowing property owners to enhance the energy efficiency of their buildings without compromising their heritage or aesthetics.
LandVac Enhance heritage vacuum glass can also be fitted into new windows and new sashes, where it enables Heritage windows to perform at similar levels to modern double and triple glazed windows. The acoustic performance of LandVac Enhance vacuum glass also reduces noise and improves occupant comfort.
Color | Clear |
Material | Glass |
Shape | Square Circle Crescent Octagon Diamond |
Length | Bespoke Guidance for specification option:
|
Width | Bespoke Guidance for specification option:
|
Height | Bespoke |
Warranty description | 15 year |
Uniclass | |
CAWS | L40/60 Insulated glass units L10/33 Proprietary windows L10/25 Aluminium windows L10/20 Steel windows L10/10 Wood windows L40/650 Insulated glass units (IGUs) – performance L40/655 Insulated glass units (IGUs) – proprietary L10/15 Wood windows L10/400 Composite windows L10/330 Aluminium windows L10/310 Steel windows L10/210 Wood windows |
General requirements | Glass generally. |
Standard | To BS 12150-1. |
Pane arrangement | Double. |
Overall thickness | 8.3 mm. |
Performance requirements | |
Fire performance | |
Integrity | Manufacturer's standard. |
Insulation | Manufacturer's standard. |
Radiation | Manufacturer's standard. |
Light | Transmittance 80%. |
Solar control | 0.58.Manufacturer guidanceG-values. |
Total shading coefficient | 0.67. |
Thermal insulation | 0.4 W/m²K. |
Sound attenuation | 39 dB.Manufacturer guidanceWeighted sound reduction index. |
Impact resistance | To BS 12150-1, toughened as standard. |
Unit build-up | |
Inner pane | |
Glass type | Single low E tough. |
Thickness | 4 mm. |
Outer pane | |
Glass type | Thermally toughened glass. |
Thickness | 4 mm. |
Cavity space fill | Vacuum cavity.Guidance for specification option: 0.3 mm. |
Dimensions | Guidance for specification option: Consult manufacturer and insert requirements.
|
Contains Red List materials | No |
Country of material origin | China |
Country of product manufacture | China |
Material | Glass |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 38.8 kg CO₂ eq/unit |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
