KS1000 TS (PIR) Insulated Roofing System

KS1000 TS (PIR) Insulated Roofing System

Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

  • QA Certificate

    QA Certificate

    Certificate type

Kingspan Insulated Panels

Tile Support (TS) through-fix, trapezoidal profiled, polyisocyanurate insulated roof panel system designed to work in conjunction with the Nu-lok™ tile roofing system.

Jump to:
+44 (0)1352 716100 www.kingspanpanels.co.uk
Application

For use with the Nu-lok™ tile roofing system. Minimum pitch: 5°; consult slate/ tile manufacturer for further requirements.

Description

Tile Support (TS) through-fix, trapezoidal profiled, polyisocyanurate insulated roof panel system designed to work in conjunction with the Nu-lok™ tile roofing system.

Features and benefits:

  • Supports slates or tiles.
  • Provides all of the advantages of insulated panel technology with the aesthetic appeal of a traditional vernacular roof finish.
  • Panels are immune to attack from mould, fungi, mildew and vermin.
  • No urea-formaldehyde is used in the construction.
  • Panels are not deleterious.
  • An air leakage rate of 3 m³/hr/m² at 50 Pa or less can be achieved when the full building envelope is constructed using Kingspan panels.
  • Cover width: 1000 mm. Also available in a cover width of 2000 mm; consult manufacturer for details.

Applications:

For use with the Nu-lok™ tile roofing system. Minimum pitch: 5°; consult slate/ tile manufacturer for further requirements.

Approvals:

CE marked to BS EN 14509: 2013.

- Fire:

  • The external and internal faces of the panel to be Class 0 in accordance with the Building Regulations when tested to BS 476: Part 6: 2009 and Part 7: 1997).
  • The panel is rated SAA when tested to BS 476 Part 3: 2004.
  • FIREsafe: FM 4471 – Class 1 Roof panel systems
  • Loss Prevention Certification Board (LPCB) approved to LPS 1181 (limited to a maximum tile weight of 54 kg/m²).

Purlins, side rails and platforms supports:

Framed roof structure to be specified separately to include the following as required:

  • Multibeam purlins.
  • Multibeam eaves beams.
  • Cold-formed cleader angles.
  • Purlin cantilevers.
  • Cladding junctions.
  • Multichannel platform supports.
  • Multichannel trimmers.
  • Rafter stays (RNA/ RNB).

Warranties:

  • Maintenance and inspection free external coating: 40 years. Manufacturer’s external coating warranty to be available on project completion and be fully transferrable for future changes of building ownership.
  • Thermal performance: 25 years.
  • Structural performance: 25 years.

General information

Uniclass 2015

Ss_30_40_55_54 Metal insulating sandwich panel roof systemsPrimary

CAWS

H43/10 Metal insulating sandwich panel

H43/120 Metal insulating sandwich panel

Specification data - Metal insulating sandwich panel roof systems

Product Reference

KS1000 TS (PIR) Roofing System

Design

Insert drawing reference or similar.

Roof pitch

Insert requirement; minimum 5°.

Panel

-

Core insulation

ECOsafe and FIREsafe polyisocyanurate (PIR)

Thermal conductivity

0.14 W/m²K

Core thickness: 150 mm; weight: 14.2 kg/m².

0.14 W/m²K

Core thickness: 150 mm; weight: 14.2 kg/m².

0.16 W/m²K

Core thickness: 120 mm; weight: 13.1 kg/m².

0.18 W/m²K

Core thickness: 115 mm; weight: 12.8 kg/m².

0.20 W/m²K

Core thickness: 100 mm; weight: 12.3 kg/m².

0.25 W/m²K

Core thickness: 80 mm; weight: 11.5 kg/m².

0.30 W/m²K

Core thickness: 70 mm; weight: 11.2 kg/m².

0.35 W/m²K

Core thickness: 60 mm; weight: 10.7 kg/m².

0.38 W/m²K

Core thickness: 50 mm; weight: 10.4 kg/m².

0.46 W/m²K

Core thickness: 40 mm; weight: 9.9 kg/m².

External facing

-

Material

Steel, 0.5 mm-thick

Colour/ Finish

Kingspan XL Forté™, colour

Consult manufacturer's literature and insert requirements.

Internal facing

-

Material

Steel, 0.4 mm-thick

Colour/ Finish

Bright white polyester

Kingspan AQUAsafe

Kingspan AQUAsafe 55

Kingspan CLEANsafe 120

Stainless steel

Panel length

See ‘Options’ and insert requirements.

Primary fasteners

-

Number/ location

See ‘Options’ and insert requirements.

Secondary fasteners

-

Number/ location

See ‘Options’ and insert requirements.

Handing

As design

Left handed

Right handed

Ridge filler

Not required

Profiled ridge filler

Cavity barriers

Cavity barriers:

Kingspan Kooltherm®

Cavity closers

Not required

Kingspan Kooltherm®

Fascia

-

Material

As roofing panel

As design

Insert requirements.

Support

Consult manufacturer and insert requirements.

Fasteners

Consult manufacturer and insert requirements.

Jointing

Consult manufacturer and insert requirements.

Soffit

-

Material

As roofing panel

As design

Insert requirements.

Support

Consult manufacturer and insert requirements.

Fasteners

Consult manufacturer and insert requirements.

Jointing

Consult manufacturer and insert requirements.

Gutters

-

Type

Not required

Kingspan Insulated Membrane Lined

Support

Consult manufacturer and insert requirements.

Fasteners

Consult manufacturer and insert requirements.

Jointing

Consult manufacturer and insert requirements.

Accessories

Consult manufacturer and insert requirements.

Flashings

Required

Not required

Rooflights

Not required

Kingspan Day-Lite Kapture

To be specified separately.

Personal fall protection

Not required

Safeside

To be specified separately.

Standard product features

Cover width:

1000 mm (Between profile ridges: 333 mm).

Single figure weighted sound reduction index (Rw):

25 dB.

Product Options

Roofing panels:

- External facing:

- Colour/ Finish:

  • Kingspan XL Forté™, colour: Multi-layer organic coating, embossed with a traditional leather-grain finish.

- Internal facing:

- Colour/ Finish:

  • Bright white polyester: For use as the internal lining of insulated panels. Standard colour is “bright white” with an easily cleaned surface.
  • Kingspan AQUAsafe: Developed for use as the internal lining of insulated panels to suit high humidity internal environments.
  • Kingspan AQUAsafe 55: For use as the internal lining of insulated panels to swimming pool internal environments.
  • Kingspan CLEANsafe 120: For use as the internal lining of insulated panels where a high level of cleanliness and hygiene is required, and the panels are to be cleaned down on a regular basis.
  • Stainless steel: For use as the internal lining of insulated panels in buildings with a very aggressive or corrosive internal environment.

- Length:

  • Standard lengths: 1.8–14.5 m, or insert drawing reference.
  • Non-standard lengths of <1.8 m or 14.5–29.3 m are available on request; consult manufacturer for details.

- Primary fasteners

  • Minimum two fasteners for each purlin position at sides of panel. Subject to wind loading; consult manufacturer's installation guide for details.
  • There may also be a requirement for applying a 4 mm diameter butyl rubber sealant / gun-grade vapour seal at the base of the side joint, dependant on project specification.

- Secondary fasteners:

- End laps:

  • 38 mm-long tail stitching screws with 19 mm sealing washers. Five per panel, applied from centre outwards, ensuring stitching screws penetrate the factory fitted stitching plate.

- Side joints:

  • Snap-on cover caps; Stitching screw or sealed rivet at eaves or through capping end lap. Anti-condensation tape (factory applied) between panels.
  • At all ridge locations, gun grade sealant to be applied across the panel side joints in line with the profiled ridge filler location, to close off the cover cap end.

Rooflights:

Rooflights are to be specified fully elsewhere - see Kingspan Light + Air or consult manufacturer for details.

Kingspan Energy:

- Solar photovoltaics:

Rooftop Solar PV can be installed onto insulated roof panels - consult manufacturer for details.

Literature
Third party certifications

Additional certifications:

  • Loss Prevention Certification Board (LPCB): Approved to LPS 1181 : Slate/tile roof panel with LPCB approval for roof applications, providing slate/ tile weight is less than 54 kg/m²
