Kronodesign® Washroom Collection - Compact Interior Laminates

Verified by manufacturer 6 months ago

Kronospan Ltd

Compact high pressure laminate (HPL) boards.

Jump to:
BIM object icon
+44 (0)1691 773361 Website

Application

Suitable for use within a range of commercial interior applications subject to high impact and moisture such as washroom cubicle systems, wall paneling, partitions and doors.

Description

Compact high pressure laminate (HPL) boards. Consists of multiple core layers with a decorative resin-impregnated paper.


Features and benefits:

  • Attractive, aesthetic appearance.
  • High mechanical strength.
  • Durable.
  • Resistant to impact, abrasion and scratching.
  • Good dimensional stability.
  • Resistant to water, steam, and hot and cold temperatures.
  • Will not corrode.
  • Anti-bacterial in accordance with ISO 22196:2011.


Consult with manufacturer directly for options and availability.

General information

Color

Grey

Ivory

Brown

Black

Cream

Show more

Finish

Smooth

Textured

Material

Laminate

Compact Grade Standard laminate (CGS).


Shape

Rectangle

Length

2800 mm

Width

1860 mm

Height

10 mm

12 mm

13 mm

Uniclass

Pr_25_71_63_15 Compact or solid grade high-pressure laminate (HPL) boardsPrimary

CAWS

N10/10 Purpose-made

N12/440 Purpose made

N12/440 Purpose made

K13/160 Proprietary

K13/160 Proprietary

N10/110 Purpose-made

N11/380 Purpose-made units

K13/150 Purpose-made

Product range

Kronodesign® / Laminates

Specification data - Compact or solid grade high-pressure laminate (HPL) boards

Grade

HPL/ EN 438-4/ CGF.

HPL/ EN 438-4/ CGS.

Fire rating

To EN 13501-1. CGF: B-s2, d0. CGS: C-s1, d0.

Thickness

10 mm.

12 mm.

13 mm.

Panel size

-

Length

2800 mm.

Width

1860 mm.

Edges

Rounded.

Finish

Double sided.

Colour

Please refer to the Kronodesign® Washroom collection and insert requirements.

-

Wear resistance

To BS EN 438-2, ≥150 rpm.

Scratch resistance

To BS EN 438-2. Smooth finishes: ≥2. Textured finishes: ≥3.

Lightfastness

To BS EN 438-2, 4–5.

Flexural strength

To BS EN ISO 178, ≥80 MPa.

TensileStrength

To BS EN ISO 527-2, ≥60 MPa.

Density

To BS EN ISO 1183-1, ≥1.35 g/cm³.

Texture

Some textures on Compact Interior may differ from the standard Laminate & MF finishes. Please consult with the manufacturer for details and availability.

Sustainability data

Country of product manufacture

Poland

Recyclability

Reusable
