Acoustic suspended raft
Acoustic Panel for Wall and ceiling applications
An architecturally-inspired curved grid-shaped ceiling product available in a range of colours and finishes. With up to 70% recycled content and finely-tuned reverberation and sound control.
Features and benefits:
10-12 weeks sea shipment
2-3 air freight
Color | Beige Black Blue Brown Green |
Material | Polyester fibre (PET) |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | 100 mm 200 mm 300 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | K40/20 Board-suspended ceiling systems K40/135 Board-suspended ceiling system |
Form | Baffle. Raft. |
Application | Ceiling mounting. |
Material | Polyester. |
Material density | 10 mm, 2 kg/m². 20 mm, 4 kg/m². |
Acoustic performance | |
Sound absorption | NRC 0.65 (20 mm), NRC 0.35 (10 mm). |
Fire performance | |
Reaction to fire | To EN 13501, Bs1,d0. |
Dimensions | |
Size (length x width) | 1200 x 300 mm. |
Thickness (overall) | 10 mm. 20 mm. |
Profile | Curved. |
Colour | Ballet. Bolero. Calypso. Chacha. Conga. Contemporary. Disco. Flamenco. Hiphop. Jive. Lambada. Latin. Mambo. Passo. Polka. Quickstep. Rumba. Salsa. Tango. Twist. Vogue. Waltz. Zumba. |
MoistureContent | Polyester fibre when exposed to an atmosphere of 50°C at 90% relative humidity for four days showed moisture absorption of less than 0.03% by weight. Polyester is not affected by moisture. |
Colour fastness | Colourfastness to Light, AATCC16(3), Class 4.5. |
Contains Red List materials | No |
Country of material origin | China |
Country of product manufacture | Hong Kong |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 70 % |
