Komfort | Defence | E Fire Rated Steel Framed Glazing and Doors - Glass Fire Screens

Verified by manufacturer 1 day ago

E30

Komfort Partitioning Ltd Variant:

Framed industrial style glazed doorsets and fixed glazing with acoustic ratings up to 44 dB (Rw).

Jump to:
BOS
+44 (0) 121 332 2550 Website

Application

Suitable for all sectors, including but not limited to: Commercial, public, education, government property and healthcare.

Description

Within a steel structure, Komfort’s Glass Fire Screens offer up to 60 minutes of protection and can be fitted along with Komfort's doors and glass partitions.


Komfort’s Defence E Fire Screens offer integrity performance only. These systems work to prevent the passage of fire, including flames and flammable gases, but not heat. They offer fire ratings from 30 minutes to 60 minutes, alongside acoustic and structural performance.

General information

Color

Beige

Black

Blue

Bronze

Brown

Show more

Finish

Powder-coated

Material

Steel

Glass

Shape

Rectangle

Square

Triangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Guidance for specification option:

Maximum screen height 4000 mm.

Warranty description

One year

Uniclass

Pr_25_71_57_60 Partition panelsPrimary

CAWS

L10/51 Glazed screen system

L10/560 Glazed screen system

Specification data - Partition panels

Unit size

-

Thickness

50 mm Wide framework.

Partition height (nominal)

-

Manufacturer guidance

Insert requirement. Maximum height 4000 mm.

Width (nominal)

-

Manufacturer guidance

Insert requirement or reference drawings. Maximum glass width 2300 mm.

Deflection allowance (maximum)

-

Head

None.

Panel partition type

Glazed.

Framing, fixing points and joints

Steel frame.

Glazed panels

-

Type

Single-glazed.

Double-glazed.

Integral blinds

Not required.

Required.

Additional features

None.

Manifestations.

Guidance for specification option:

Insert requirement or reference drawings.

Graphics.

Guidance for specification option:

Insert requirement or reference drawings.

Door arrangement

-

Type

Single latched doors.

Guidance for specification option:

Width: 500–1610 mm.

Maximum height: 3393 mm.

Double latched doors.

Single unlatched doors.

Guidance for specification option:

Width: 532–1200 mm.

Maximum height: 2540 mm.

Double unlatched doors.

Locking

Locking.

Non-locking.

Manufacturer guidance

Refer to the Fire Screens Design Guide for locking options.

Door frames

Steel.

Trims

None.

109 Glazing bar.

Hardware

Oval back mitre sprung lever.

Oval back radius sprung lever.

Cranked D pull handles, 600 mm.

Cranked bar pull handles, 720 mm.

Cranked bar pull handles, 1240 mm.

Cranked bar pull handles, 1760 mm.

Angled pull handles, 700 mm.

Angled pull handles, 1200 mm.

Angled pull handles, 1800 mm.

Dorma C-Lever ProRadius Lever Handle.

Guidance for specification option:

Wireless access control handle.

Dorma C-Lever ProMitre Lever + S-Module.

Guidance for specification option:

S-module makes the handle hard-wired, with a cable loop for connection into the existing building system for the centralised control of all doors in case of fire or emergency.

Dorma C-Lever ProMitre Lever Handle.

Guidance for specification option:

Wireless access control handle.

Dorma C-Lever ProRadius Lever + SModule.

Guidance for specification option:

S-module makes the handle hard-wired, with a cable loop for connection into the existing building system for the centralised control of all doors in case of fire or emergency.

Assa Abloy Eff Eff 143 Electronic Strike.

U10002DS-U Fail-Safe Maglock.

Manufacturer guidance

  • Sprung Lever handles are available in satin stainless steel finish only.
  • Cranked/ angled pull handles are available in satin stainless steel or powder coated to any RAL or BS colour.
  • Dorma C-Lever Pro is available in satin stainless steel or black (special purchase item).
  • Refer to the Fire Screens - Design Guide for details.

Fire resistance

E30.

AcousticRating

Guidance for specification option:

37–44 dB (Rw). Insert requirements.

Manufacturer guidance

Please note that in an on-site acoustic test, a glazed partition or doorset can result in a 3 dB to 5 dB lesser performance than under laboratory conditions. This can be further affected by ambient noise levels on the receiving side of the test sample and by poorly insulated abutments and voids above and below the partition which will result in a ‘flanking’ path for audible sound.

Door closers

Dorma TS93 EN 2-5 Sliding Arm Cam-Action Closer.

Guidance for specification option:

Arm and cover kits are available in stainless steel or polyester powder-coated to any RAL or BS Colour Code. Consult manufacturer and insert requirements.

Sustainability data

Contains Red List materials

No

Country of material origin

Switzerland

Country of product manufacture

United Kingdom

Recyclability

Up to 100% steel

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Fire Screens - Design Guide

Fire Screens - Design Guide

Case studies

81 Piccadilly, London

81 Piccadilly, London

MediCity Nottingham

MediCity Nottingham
