Kestrel Aluminium Commercial Doors And Framing System
Verified by manufacturer 4 months ago
Double door
Double door
An aluminium alloy range of low rise entrances and doors.
Application
Suitable for all types of buildings where entrances and doors of high traffic, commercial nature are required.
Description
Kestrel Aluminium Systems Commercial doors and framing are a range of low rise entrances and doors, designed to industry standards.
The system is based on a common box section size of 100 x 45 mm for both double and single glazed options, with a two screw port feature for inherent strength. Construction consists of main vertical members with horizontal transoms spanning between. Framing profiles are square cut and assembled by driving screws into extruded receptacles in the corresponding section. All loads are transmitted to a supporting structure via purpose designed fixings and fixing details. The framing is not self supporting. Weatherstripping is woven pile, polypropylene backed, premier density.
Door sections are square cut and assembled with extruded engineered cleats and M10 tie rods for additional strength and robustness.
Infills of glass are glazed by shuffle glazing the infill into jamb glazing pockets. Cill and head beads snap-in internally or externally depending on the application to give a flush appearance. All vertical door beads are mechanically fixed externally for security.
Features and benefits:
- Pivot, hinged and sliding doors can be constructed from the section range.
- 45 mm and 50 mm window systems can also be used with the framing.
General information
Finish | Anodized Powder-coated Mill |
Material | Aluminium |
Shape | Square Rectangle |
Length | Bespoke |
Width | Bespoke Manufacturer guidanceConsult the manufacturer product manual for detailed installation instructions and contact the manufacturer technical department for details of the maximum spans and loadings applicable to the site conditions. |
Height | Bespoke |
Warranty description | Ten year Guidance for specification option: Kestrel Aluminium Profiles have a ten-year warranty. See powder coating guarantee. |
Uniclass | |
CAWS | L20/55 Doorsets L20/480 Doorsets |
Specification data - Aluminium doorsets
Standard | To BS EN 12020-2:2001, BS 3987:1991, BS EN 12206-1:2021. |
Configuration | Double Action Entrance Doors, 24 mm double glazing.Double Action Entrance Doors with finger guard.Single Action Entrance Doors open in with Electric Strike Release.Rebated Fire Exit Doors Single Action open out. |
Doorset size | 1100 x 2500 mm.Guidance for specification option: Maximum width x height. |
Performance | |
Fire performance | |
Fire integrity | Unrated. |
Frame | |
Material | Aluminium. |
Finish | |
Coating | Anodizing to BS 3987.Powder coating to BS 6496. |
Colour | Manufacturer guidanceContact manufacturer for available colours. |
Door leaf | |
Material | Aluminium. |
Glazing | |
Type | Manufacturer guidanceThe system will accommodate a range of glazing thicknesses from 6 to 11 mm for single glazed units and from 24 to 28 mm double glazed units. Glass is set dry between TPE gaskets internally and externally. Consult manufacturer and insert requirements. |
Finish | |
Coating | Anodizing to BS 3987.Powder coating to BS 6496.Etched and anodised silver. |
External colour | Manufacturer guidanceContact manufacturer for available colours. |
Internal colour | Manufacturer guidanceContact manufacturer for available colours. |
Hardware | Automatic door gear to be specified and supplied by specialist fabricator or installer.Guidance for specification option: Double Action Entrance Doors only. Handles to comply with DDA.KAS504.H MS 2200 Hooklock with KAS523 Europrofile cylinder.Guidance for specification option: Double Action Entrance Doors with finger guard only. KAS574 Concealed Overhead Closer with hold open.Guidance for specification option: Double Action Entrance Doors with finger guard only. KAS571 Shoot Bolts in Silver anodized finish (double doors only).Guidance for specification option: Single Action Entrance Doors open in with Electric Strike Release only. KAS505 4710 dead-latch and KAS521 cylinders.Guidance for specification option: Single Action Entrance Doors open in with Electric Strike Release only. KAS505 4750 dead-latch and KAS521 cylinders.Guidance for specification option: Single Action Entrance Doors open in with Electric Strike Release only. KAS540 (Single door) electric strike release.Guidance for specification option: Single Action Entrance Doors open in with Electric Strike Release only. KAS541 (Double door) electric strike release.Guidance for specification option: Single Action Entrance Doors open in with Electric Strike Release only. KAS574 Concealed Overhead Closer NON hold open.Guidance for specification option: Single Action Entrance Doors open in with Electric Strike Release only. KAS404 door stop.Guidance for specification option: Single Action Entrance Doors open in with Electric Strike Release only. Fire exit doors single action open out, panic bar.Guidance for specification option: For Rebated Fire Exit Doors Single Action open out.
Panic bars comply with BS EN 1125:2008. Fire exit doors single action open out, panic latch.Guidance for specification option: For Rebated Fire Exit Doors Single Action open out.
Panic bars comply with BS EN 1125:2008. Manufacturer guidanceComprehensive range of door hardware to function with door and frame profiles as specified. Consult the manufacturer's technical literature for information on recommended locks and cylinders. |
Jointing | Mechanical. |
Glazing | 6 - 11 mm (single glazing). 24 - 28 mm (double glazing). |
U-value | 3.5 W/m²K. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 4.0 kg CO₂ eq/kg Self declared |
Recyclability | Aluminium building products are collected and recycled at end-of-life very efficiently, and the end-of-life recycling rate for aluminium is >90%. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 79 % |
