Description

An injection-moulded polypropylene box with a polyester foam gasket fixed to the sides.

The product will limit unwanted air leakage between a ceiling void and an external wall cavity and thereby minimize heat loss by air.

Features and benefits:

  • Available in a range of sizes to fit on the end timber joists and I-beams.
  • Knock-out tabs around the box flange provide slots for restraint straps to be fixed to the joist and wall where required.
  • Joist seals solve the problem of air leakage associated with built in timber joists.
  • They are designed to meet the requirements of Part L Building Regulations regarding increased insulation and air leakage and provide an effective and easy to install solution.

General information
Size

225 x 40 mm

225 x 48 mm

225 x 65 mm

225 x 75 mm

225 x 90 mm

225 x 100 mm

225 x 150 mm

302 x 38 mm

302 x 45 mm

302 x 60 mm

302 x 76 mm

302 x 90 mm

302 x 120 mm

302 x 150 mm

302 x 180 mm

Uniclass 2015
Softwood sections (Pr_20_76_88_83)Primary
Specification data - Softwood sections
Product Reference

G912

G913

Size

225 x 40 mm

225 x 48 mm

225 x 65 mm

225 x 75 mm

225 x 90 mm

225 x 100 mm

225 x 150 mm

302 x 38 mm

302 x 45 mm

302 x 60 mm

302 x 76 mm

302 x 90 mm

302 x 120 mm

302 x 150 mm

302 x 180 mm

Product Options

Product reference:

- Type G912 Joist seal:

  • Joist height: 225 mm.
  • Joist width: 40–150 mm.
  • Blockwork depths: 100–140 mm

- Type G913 Joist seal:

  • Joist height: 302 mm.
  • Joist width: 38–180 mm.
  • Blockwork depths: 100–140 mm.

Third party certifications
  • CERAM Building Technology.: Tested to a method based on MOB PF2 PS/SPU and CIBSE Document TM 3: 2000
  • Local Authority Building Control.: 327-12-7079
  • Warrington Fire and Research: 142893 : BS 476: Part 22
