QA Certificate
Certificate type
Ultra-matt finishes which minimises surface reflectance and offers the closest alternative to various shades of anodised aluminium.
Intended for use on architectural aluminium and galvanized steel.
Range of ultra-matt finishes which minimises surface reflectance on architectural aluminium and galvanized steel.
Features and benefits:
ColorPlease refer to D2015 Precis Ultra Matt Colour Card for available colours | - |
Finish | Matt Ultra matt solid. Metallic |
Material | Polyester |
WarrantyDescription | 40 year (UK application only). |
Uniclass | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H11/130 Sun screens H11/135 Doors H11/140 Louvres H11/145 Integrated access equipment H13/115 Structural glass assembly H31/110 Metal H31/120 Metal H43/120 Metal insulating sandwich panel H92/120 Rainscreen cladding H92/130 Major non-standard components L10/20 Steel windows L10/25 Aluminium windows L10/310 Steel windows L10/315 Steel windows L10/33 Proprietary windows L10/330 Aluminium windows L10/335 Aluminium windows L10/400 Composite windows L10/45 Rooflights L10/460 Rooflights L10/550 Glazed metal screens null Glazed screen system L10/650 Metal louvres L20/280 Doors L20/370 Door frames L20/480 Doorsets L35/410 Aluminium components L35/420 Carbon steel components R10/11 Aluminium gutters R10/30 Aluminium pipework R10/311 Aluminium gutters R10/335 Galvanized steel gutters R10/370 Aluminium pipework R10/395 Continuously hot dip coated steel pipework - pressed Z31/120 Powder coating materials |
Standard | To aluminium: BS EN 12206-1/Qualicoat.To galvanized steel: BS EN 13438. |
Powder formulation | Polyester TGIC free. |
Colour | Refer to Interpon D2015 Précis colour card for availability of colours and insert requirements. |
Accelerated weathering | Suntest DIN EN ISO 11341: Gloss retention ≥90% (1000 h). QUV-B 313: Gloss Retention ≥ 50% (600 h). |
Acetic acid salt spray resistance | 1000 h: Infiltration at cross-section ≤1 mm; no blistering. |
Adhesion | Gt0 (2 mm crosshatch). |
Chemical resistance | Generally good resistance to acid, alkalis and oil at normal temperatures. |
Colour stability at elevated temperatures | Excellent. |
Coverage | 3.5–4 m². |
Dry film thickness | 60 microns. |
Fire classification (EN 13501-1) | A2-s1, d0. |
Flexibility | ≤5 mm (Cylindrical mandrel). |
Florida exposure | Compliant with Qualicoat Class 2/GSB Master requirements after 3 years Florida and Qualicoat Class 2/GSB Master requirements after 5 years Florida. |
Gloss level | 5–15 gloss units. |
Hardness | F min. |
Impact resistance | Reverse: ≥20 in lb. |
Storage | Dry cool conditions. (Below 25°C). |
Embodied carbon | 3.70 kg CO₂ eq/kg |
Platform | Compatible | Version | Certified to |
---|---|---|---|
![]() | IFC2X3 | 1 | 1.3 |
![]() | Revit 2016 | 2 | 2.0 |
