Integrated fridge/ freezer cabinet

Verified by manufacturer 8 months ago

SieMatic Holding GmbH

Handle-less tall cabinet for an integrated fridge freezer, with one compartment and two doors, SieMatic hinges. 207.8 cm high, 61 cm deep and 60 cm wide.

Jump to:
BIM object icon
+44 (0)161 660 6895 Website

Description

SieMatic S2, handle-less tall cabinet for an integrated fridge freezer, with one compartment and two doors. 207.8 cm high, 61 cm deep and 60 cm wide. Top door height 132.7 cm , and bottom door height 74.5 cm.

The carcass is made up of white, two-sided directly applied triple layer furniture board (emission class E1), 1.6 cm thick. Finished sides can be planned in door front colors. The back wall is 3.0 mm-thick hardboard covered with lacquer which protects against moisture. The carcass front edge is an ABS edge, the colour is preselected to match the door front colour but can be changed upon request or fitted with an aluminum coloured edge. All other carcass edges sealed with melamine edging. The carcass front edge is also fitted with a safety profile dust seal in white or grey.

Door styles available in the SieMatic colour system in laminate matt, laminate wood, laminate gloss, SimiLaque velvet-matt, SimiLaque high-gloss, Lacquer matt or gloss, veneer.

General information

Color

The SieMatic colour system.

-

Finish

Laminate

Veneer

Material

Triple layer furniture board.

Lacquer

Includes Similacquer.

Shape

Rectangle

Size

610 x 600 x 2078 mm

WarrantyDescription

Five year

Uniclass

Pr_40_30_87_42 Kitchen drawer unitsPrimary

CAWS

N11/310 Fitted base units

N11/10 Fitted base units and wall units

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
IFC
-

1

Revit
-

1
