Inspirations - Polyester Powder Coating

Verified by manufacturer 10 days ago

Powdertech (Corby) Ltd Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

  • QA Certificate

    QA Certificate

    Certificate type

  • EPD

    EPD

    Certificate type

New, exciting and inspiring colours in the Inspirations range is part of Powdertech's commitment to offering colours that are a little bit different, thought provoking or interesting.

Jump to:
BIM object icon
+44 (0)1536 400890 Website

Application

  • Base material. Mild steel, galvanized steel or aluminium.
  • Material form. Solid, perforated, expanded or fabricated.
  • Application. Solar control; curtain wall; facade; cladding; capping; trims; soffit and associated components; balconies; balustrade and handrail. Architectural, retail, commercial and residential.

Description

The Inspirations range is part of Powdertech's commitment to offering colours that are a little bit different, thought provoking or interesting. Six carefully selected colour palettes have been created using tones and textures to reflect different landscapes, both natural and man-made.

We are constantly updating the range changes to keep it fresh and relevant, without compromise on quality and performance.


Features and benefits:

  • Defining six different environments; coastal, terrain, urban, industrial, lowland, upland, sky and space.
  • Tones and textures in each palette share an affinity, creating a particular style.
  • High performance corrosion protection and weather resistance.
  • Excellent durability and colour stability.
  • All powders are Qualicoat Class 1 or class 2 approved.
  • Conform to BS EN 12206-1.
  • Resistance to boiling water, no blistering and no loss of adhesion.
  • Cylindrical mandrel bending, tested to ISO 1519, 5 mm mandrel, no cracking or detachment.

General information

Color

Full details at: Landscape™ | Powdertech Corby

-

Finish

Fine textured or smooth finishes

Smooth

Textured

Gloss

Matt

Metallic

Show more

Material

Powder coating material is a thin layer of pigmented polyester applied to a base metal.

Polyester

Shape

Formless

Warranty description

25 year

For C2 and C3 environments: 25-year warranty for gloss, colour and adhesion.

For C4, C5I and C5M environments: Guarantees are conditional on project location, environmental conditions and pre-contract approval.

Uniclass

Pr_35_31_68_66 Powder coatingsPrimary
Pr_35_31_22_55 Multicoloured finish spatter coatings
Pr_35_31_22_54 Multicoloured coatings

CAWS

R10/321 Combined fascia, soffit and gutter

R10/13 Combined fascia, soffit and gutter

L35/420 Carbon steel components

L35/410 Aluminium components

L30/560 Proprietary balustrades

L30/550 Purpose-made balustrades

L30/55 Proprietary balustrades

L30/50 Purpose-made balustrades

L10/650 Metal louvres

L10/560 Glazed screen system

L10/550 Glazed metal screens

L10/54 Louvres

L10/51 Glazed screen system

H92/130 Major non-standard components

H13/115 Structural glass assembly

H20/150 Sheet cladding (attached to metal support systems)

H20/155 Sheet cladding (attached to timber battens)

H31/120 Metal

H92/830 Powder coating

H20/10 Sheet cladding

H31/10 Metal

H43/10 Metal insulating sandwich panel

H11/830 Powder-coating

H11/130 Sun screens

H11/110 Curtain walling

H11/137 Windows/ opening lights

H11/135 Doors

H11/140 Louvres

H11/145 Integrated access equipment

H92/120 Rainscreen cladding

Z31/120 Powder coating materials

H43/120 Metal insulating sandwich panel

Specification data - Powder coatings

Standard

To BS EN 12206-1 and ISO 13438.

Powder formulation

Manufacturer's standard.

Gloss level

25—35%.

At 60ᵒ (Smooth finish, matt).

55—70%.

At 60ᵒ (satin).

<10%.

At 60ᵒ (texture).

Film thickness

>60 µm.

Adhesion

Rating 0.

Dry adhesion cross hatch (ISO 2409) Rating 0, no coating detachment, wet adhesion (ISO 2409) after 1 hour pressure cooker rating 0, no detachment.

Sulphur dioxide resistance

24 cycles no infiltration.

Exceeding 1mm from the scribe, no change in colour or blistering in excess of 2(S2) to ISO 4628-2.

Constant humidity resistance

1000 hours.

To ISO 6272-2, <1mm scribe creep. No blistering in excess of 2(S2) to ISO 4628-2.

Impact resistance

No cracking or detachment.

Tested to ISO 6272-2: Reverse Impact test.

Erichsen cupping

No cracking or detachment.

Tested to ISO 1520 minimum 5 mm indent.

Permeability

No blistering or coating detachment.

Scratch resistance

E2 Pass.

To BS 3900.

Pre-treatment

Aluminium: Titanium-zirconium (TiZr) non-chrome six-stage pre-treatment.

Galvanized steel: Silane (oxsilan) non-chrome eight-stage pre-treatment.

Not required/ other.

Consult manufacturer for details for surfaces other than aluminium or galvanized steel.

Application method

Corona discharge system.

Powder application.

Fire rating (to BS EN 13501)

A2-s1, d0.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

Guidance:

LCA: A1-A3. 3.29 to 5.06 Kg CO2 eq/kg. Contact Powdertech for more information.

5.24 kg CO₂ eq/kg

Recyclability

Does not affect the recyclability of the base material

Recycled content

0 %

EPD
