IM Fleece Tape: High-Performance Airtight Membrane for Sealing and Joint Protection - Airtight Window & Doors Sealing Tapes

Verified by manufacturer 2 days ago

Intelligent Membranes

The very best airtightness tape for windows and connecting joints. Polyamide film covered on one side with non-woven for outside and inside sealing of window connection joints with adhesive coating.

Jump to:
BOS
+44 (0)1223 208174 Website

Application

Product Application

  • Internal and external sealing of window and door perimeter joints.
  • Airtight sealing of floor/wall, wall/ceiling, and wall/wall junctions.
  • Connection sealing for curtain walls and façade systems.
  • Airtightness detailing at vertical and horizontal joints.
  • Sealing wall/roof interfaces, including steel deck connections.
  • Airtight sealing around service penetrations.
  • Plasterable finish for integration into internal wall linings.

Description

IM Fleece Tape – Airtight & Vapour Control Window and Joint Sealing Tape

IM Fleece Tape is a fleece-reinforced airtight membrane tape with a variable SD value, designed for both internal and external sealing of window connection joints, wall junctions, and other critical airtightness details. The tape combines a polyamide membrane with a non-woven surface for excellent plaster adhesion, and a modified HMPSA adhesive layer for strong, durable bonding to multiple substrates.

Key Features & Benefits

  • Airtight and watertight – provides a continuous barrier to prevent air leakage and moisture ingress.
  • Variable SD value – suitable for both internal and external use in airtightness and vapour control applications.
  • Pre-set fold line – ensures precise fitment in corners and junctions.
  • High adhesion and flexibility – bonds to concrete, brick, timber, PVC, and metal, accommodating building movement.
  • Plasterable fleece face – integrates seamlessly with mortar or plaster finishes.
  • Available sizes – 75 mm, 100 mm, 150 mm, and 200 mm widths (all 25 m rolls).

Material Composition

  • Membrane: Polyamide film with non-woven substrate.
  • Adhesive: Modified HMPSA.
  • Liner: Release-foil.

Application Guidance

  • Surfaces must be dry, clean, and free from dust, grease, or release agents.
  • Press firmly with a pressure roller for optimum adhesion.
  • Suitable for installation with window fitting or for retrofitting after installation.
  • Non-woven surface can be plastered or rendered over immediately.

Use Cases

  • Window and door perimeter sealing.
  • Floor/wall and wall/ceiling junctions.
  • Curtain wall and façade interfaces.
  • Vertical and horizontal joints.

General information

Color

White

Other

Finish

Coated

Guidance for specification option:

Adhesive coating.

Material

Fleece

Polyamide

Shape

Rectangle

Other

Length

25000 mm

Width

Bespoke

Height

Bespoke

Uniclass

Pr_35_90_87_69 Polymer-based adhesive sealant tapesPrimary

CAWS

L10/75 Sealant joints

L10/810 Sealant joints

Product range

Airtight Tapes

Specification data - Polymer-based adhesive sealant tapes

Classification data

Material

Polyamide.

Bond

Single-sided modified HMPSA adhesive.

Properties

-

Reaction to fire

To DIN EN 13501, Class E.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0%.

Air permeability

To DIN EN 12114 (a-value): <0.1 m³.

Size

75 mm wide.
100 mm wide.
150 mm wide.
200 mm wide.

Colour

White.
Other.

Guidance for specification option:

Other colours available upon request, consult manufacturer.

Overall thickness

0.31 mm.

Guidance for specification option:

(no adhesive).

Elongation at break

To DIN EN ISO 527-3, Longitudinal: 135%; Lateral: 206%.

Breaking load

To DIN EN ISO 527-3, Longitudinal: 59 N/ 15 mm; Lateral: 45 N/ 15 mm.

Sd value

To DIN EN ISO 12572, 0.14–26.8 m.

Application temperature

-22° C to +60° C.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Material

Fleece
Polyamide

Recyclability

Not recyclable

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %

Expected Life

25 year

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Intelligent Membranes Airtight Fleece Tape Install Guide

Intelligent Membranes Airtight Fleece Tape Install Guide

Intelligent Membranes Airtight Fleece Tape Product Sheet

Intelligent Membranes Airtight Fleece Tape Product Sheet
