iCOM Access Control System
Description

Controlled access system. The iCOM access door control system is the result of a joint venture between Allgood and SALTO Systems.

The systems offer the choice of the most convenient user ID-Technology with a variety of programming methods together with all the advantages of a standard access control system, including time-zoning and audit trails.

The flexibility of the Allgood/ SALTO system allows for a free choice of lever handles.

iCOM:

  • iCOM allows on-line and off-line doors to be controlled by the same token fob.
  • The COMfort lock is controlled by battery, readers will control the main passage doors.

Features and benefits:

  • Maximum of 64 000 users per escutcheon.
  • Locking plan for maximum 64 000 doors
  • Audit trail of last 1000 events in non-volatile flash memory.
  • 30 minutes' fire rated.
  • Intuitive use through a smart electronic touch key.
  • Possibility of using SALTO Virtual Net
  • High resistance to weather damage.
  • Available with oval cylinder profile.
  • Variations available to suit most applications.

Specification data

Product Reference

iCOM Access Control System

Accessories

Not required

70100S4 SALTO Virtual Net (SVN)

70108S0 SALTO Virtual Net (SVN)

70108S5 SALTO Virtual Net (SVN)

70210SO

COMfort lock with standard lever, the internal lever is always free for escape situations, the external lever is controlled.

70210S1

As 70210SO, but with a choice of lever handles.

70205X0

iCOM internal reader, for use with electric locks on high-frequency doors.

70205S1

iCOM external reader.

70909X9

iCOM control unit for on-line reader.

70909X8

As 70909X9, but for off-line readers.

70206X1

iCOM Portable programming device (PPD).

70206X0

iCOM encoder (ENC).

70251X2

iCOM 512 byte button, black.

70291X3

iCOM 512 byte button, red.

70291X2

iCOM 2k button, black.

70291X3

iCOM 512 byte button, red.

Product Options

Accessories:

Blue, yellow and green buttons are available on request. Consult manufacturer for details.
