Hybrid Series 1 Composite Entrance Door


High performance composite door solution for new and refurbishment projects. It offers the benefits of long life operation and low maintenance of aluminium externally with the high insulation, environmentally focused benefits of responsibly sourced engineered timber internally.

Hybrid doors are available in single and double leaves, utilizing low thresholds.


  • Constructed using mitred joints on both the aluminium and timber frames.
  • Using a mechanical corner joint on the aluminium frame and dovetail keys on the timber frame enables the frames to be constructed without the need for complicated production processes.
  • Integral transoms and mullions are inserted by scribing the ends and screw fixed to the frame.
  • A sealant is used on all metal joints, the timber mainframe sections are mitre jointed using a unique closed joint method.
  • Opening leaves frames are designed to be inserted directly into the outer frames on butt hinges.

General information

Uniclass 2015

Pr_30_59_24_16 Composite doorsetsPrimary


L20/480 Doorsets

L20/55 Doorsets

Specification data - Composite doorsets

Product Reference

Hybrid Series 1 Composite Entrance Door


Double door

Single door

Colour/ Finish


Clear lacquered

Mill finish

Polyester powder coated

Insert details.

Water based paint

Insert details.

Standard product features


- External:

Extruded aluminium alloy 6060 or 6063 T6 to BS EN 755–9.

- Internal:

  • Purpose engineered profiles in spruce laminated timber (Scantlings); in principle without faults (knots and flaws).
  • Certificated to IFT Rosenheim, DIN EN 204 glued with D4 glue.
  • Finger joints in outer layer minimum 500 mm centres.
  • Moisture content: 12% +/- 2%.
  • PEFC /04-32-0042 Certified.

Consult manufacturer for other timber species, special order.

Performance (Exposure category to BS 6375–1):

  • Air permeability: 600 pa.
  • Water tightness: 600 pa.
  • Wind Resistance: 2400 pa.


- Open in:

  • Double door: 1.31 W/m²K.
  • Single door: 1.35 W/m²K.

- Open out:

  • Double door: 1.40 W/m²K.
  • Single door: 1.51 W/m²K.


Open out single door: Tested to PAS23/24, security hardware required.

Product Options

Typical sizes (w x h):

  • Single door: 900 x 2100 mm.
  • Double door: 1800 x 2100 mm.

Colour/ Finish:

Available in four finishes including:

  • Polyester powder coating to BS EN 12206-1.
  • Anodized finish to BS 3897.
  • Clear lacquered.
  • Painted timber, consult manufacturer for details.
