Heritage Period Doors - Single

Verified by manufacturer 2 months ago

TRC Windows Third party certifications:
  • CHAS

    CHAS

    Certificate type

  • Constructionline

    Constructionline

    Certificate type

  • Health & Safety Accreditation

    Health & Safety Accreditation

    Certificate type

Single heritage period door.

Jump to:
+44 (0) 1858 469225 https://www.trcwindows.co.uk

Application

Suitable for refurbishment and listed buildings.

Description

Period timber doors carefully styled to suit heritage and conservation projects. They are a good choice for replacement doors in listed buildings; while also complementing high-specification new-build designs.


Features and benefits:

  • Available as heritage French doors and single timber doors, these period doors preserve the original design integrity while fulfilling acoustic and thermal containment demands.
  • Original design touches add distinction, such as traditional putty for the optional glazing panels.
  • Bespoke windows and doors are available; consult manufacturer for details.
  • FSC certified.


Guarantees:


TRC Contracts Ltd offers robust guarantees on all TRC window ranges we supply and install. The following general terms apply on all new windows:

  • Expected Lifespan: All our windows are designed with a 60-year service life guarantee.
  • Manufacturing and Material Defects: 10-year guarantee.
  • Finishes: The standard three-coat opaque finished joinery is guaranteed for 10 years, and the stain finishes are guaranteed against blistering or flaking for six years.
  • Seals: The seals on double-glazed units are guaranteed for 10 years (from the date of delivery).
  • Ironmongery: Functional failure is guaranteed on ironmongery for two years.


General information

Color

Multiple options available. RAL classic range.

Black

Brown

White

Finish

Available in dual finish, RAL classic range and stain. Insert requirements.

Painted

Material

Timber

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

WarrantyDescription

Ten year

Uniclass

Pr_30_59_24_97 Wood doorsetsPrimary

CAWS

L20/410 Wood doorsets

L20/55 Doorsets

Specification data - Wood doorsets

Third party accreditation

FSC certified.

Standard

To BS EN 6375-1, EN ISO 10077 and ISO 9001.

Configuration

As drawings.

Insert requirements.

As schedule.

Insert requirements.

Format

Open in, open out.

Performance

-

Acoustic performance

To BS EN ISO 10140-2, sound reduction index Rw ≤36 dB minimum.

Strength and durability

To BS EN 1192.

Thermal

To BS EN ISO 10077-1, ≥1.6 W/m²K.

Frame

-

Material

Hardwood.

Species

Engineered Accoya.

European oak.

Engineered hardwood.

Engineered redwood.

Threshold

Part M compliant aluminium threshold.

Perimeter seals or inserts

EPDM weatherseal.

Finish

Factory finished.

Three coat spray applied factory finish using water based micro-porous paint. Dual finish, RAL classic range.

Colour

Colour from RAL classic range.

As standard.

Dual finish or stain.

Optional.

External

Stain.

RAL.

Internal

Stain.

RAL.

Door leaf

-

Thickness

60 mm.

40 mm.

Core

Solid core.

Panel details

Not required.

24 mm insulated flat panel.

34 mm insulated raised and fielded panel.

34 mm insulated flat panel with bolection moulding.

34 mm insulated grooved panel.

Perimeter seals

Weather.

Finish

Factory stain.

Colour

-

External

Stain.

RAL.

Internal

Stain.

RAL.

Glazing

-

Type

14 mm double glazed Slim Sightline (8.5 mm) unit.

Standard, 4 mm/ 6 mm argon/ 4 mm low-E externally glazed using Heritage hand-faced putty.

12 mm double glazed Slim Sightline (8.5 mm) unit.

4 mm/ 4 mm argon/ 4 mm low-E externally glazed using Heritage hand-faced putty.

6 mm toughened single glass externally glazed.

Using Heritage hand-faced putty.

Double glazed, 14 mm thick.

Standard; 4/6/4 low-E top sash, 4/6/4 toughened bottom sash.

Single glazed, 4 mm thick toughened single glass, externally glazed.

Using Heritage hand-faced putty.

Single glazed, 4 mm thick, toughened.

Single glazed, 6 mm thick, toughened.

Manifestation

Yes.

Beading

-

Type

External.

MoistureContent

12–19%.

Sash

100 x 68 mm.

Configuration

Double French doors.

Single door.

Frame (w x d)

60 x 90 mm.

Standard.

40 x 154 mm hardwood sapele timber sub sill.

With low level aluminium threshold (mobility compliant).

Low level aluminium threshold (mobility compliant), no timber sub sill.

Solid bars

24 x 68 mm ovolo.

Standard.

As drawing.

Perimeter spacer bars

White.

Standard.

Black.

Ironmongery

Black lever handle.

Brass lever handle.

Polished chrome lever handle.

Satin chrome lever handle.

Stainless steel lever handle.

Letter plate

Not required.

Polished stainless steel.

PVD stainless steel.

Satin stainless steel.

Horns

Not required.

As drawing.

Hinges

3D adjustable projection hinges.

Black fixed pin hinges.

Brass fixed pin hinges.

Satin chrome fixed pin hinges.

White fixed pin hinges.

Environmental information

Contains Red List materials

No

Country of material origin

Cameroon

Country of product manufacture

Lithuania

Embodied carbon

0.5 kg·CO₂e/kg

Recyclability

Recyclable parts of product timber, glass, gaskets.

Yes.

Recycled content

0 %

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit

Revit 2017

1

2.1
Download now from NBS National BIM Library

Literature

Period Doors

Period Doors

Case studies

87 Avenue Road, London

87 Avenue Road, London

Douay Martyrs Catholic School

Douay Martyrs Catholic School

The Star and Garter, London

The Star and Garter, London

University Arms Hotel

University Arms Hotel

Third party certifications

CHAS

CHAS

CHAS standards

Constructionline

Constructionline

Constructionline Silver

Constructionline

Constructionline

Constructionline Social_Value

Health & Safety Accreditation

Health & Safety Accreditation

Health & Safety / Acclaim Accreditation
