Heritage Aluminium Window

Application

Suitable for any home.

Description

Thermally broken aluminium windows with double or triple glazing available.


Features and benefits:

  • Highly secure option with reverse espaq locks, Secured by Design, PAS 24 and Document Q approval.
  • Option of glazing bars in a configuration of your choice, offering slim sightlines and 70.5 mm frame.

General information

Color

All RAL colours are available plus dual colour options.

-

Finish

Powder coated

To minimum 60 microns.

Material

Aluminium

Size

Made to measure.

-

WarrantyDescription

Ten years

Ten-year guarantee.

Uniclass 2015

Pr_30_59_98_02 Aluminium window unitsPrimary

CAWS

L10/330 Aluminium windows

Specification data - Aluminium window units Enhanced data

Dimensions and configurations

Made to measure.

-

Product performance

-

Safety

-

Security level

To PAS 24.

Thermal

-

Whole window U-value

1.4 W/m²K.

Double glazing.

1.3 W/m²K.

Triple glazing.

Frame

-

Profile

Extruded aluminium.

Mitred corner joints.

Finish as delivered

-

Coating

Powder coating to BS EN 12206-1.

To minimum 60 microns.

Colour

All RAL colours are available plus dual colour options

-

Ventilator

Trickle vent/ Black.

Trickle vent/ White.

Trickle vent/ Brown.

Trickle vent/ Anthracite grey (7016).

Trickle vent/ Colour matched.

Glazing or infill

-

Requirements

Double Glazed Sealed Units: 6/16/6 toughened , argon gas filled cavities , centre pane U-value 1.0 W/m²K.

Double Glazed Sealed Units : 4/18/6.8 laminated, argon gas filled cavities, centre pane U-value 1.1 W/m²K.

Triple Glazed Sealed Units: 4/12/4/12/4 toughened, argon gas filled cavities, centre pane U-value 0.8 W/m²K.

Triple Glazed Sealed Units: 4/10/4/12/6.8 laminated, argon filled cavities, centre pane U-value 0.9 W/m²K.

Product Reference

Heritage Aluminium Window

Seals

EPDM high wear / UV / Water resistant.

Locking system

Keyed handles operating espagnolettes with multipoint lock.

Ironmongery

Black.

White.

Satin silver.

Polished chrome.

Polished gold.

Show more

Environmental information

Country of product manufacture

United Kingdom
