Hawa Folding Concepta III 20/25 Pull & Push - Door furniture

Furniture hardware for bi-folding cabinet pocket doors with a maximum panel weight of 25 kg (50 kg for a pair).

Features and benefits:

• Door width: 440–700 mm.
• Door height: up to 20kg 1200-2200 mm.
• Door height: up to 25kg 1900-2700mm.
• Suitable for door panel thickness of 18–26 mm.
• Pull version for panels with handles, or Push version for panels without handles.
• Flush cabinet doors can be fully opened – two doors can be folded and slid into furniture cabinets or wall niches at either the side.
• Left and Right hand sets available.
• Systems with one pair of folding doors at both sides can be incorporated without separating walls when using the optional reinforcement profile.
• Quiet movement due to guidance of the upright.
• Black anodized profiles create an elegant aesthetic.
• Two-piece and four-piece configurations available (in combination with Hawa Concepta, three-piece configurations are also possible).
• Helps to utilize available room space.
• Hardware is discreetly integrated into the overall cabinet appearance.
• All necessary adjustments can be made from the front.
• Two different centering solutions are available so that the closed doors terminate flush beneath each other or to the outside.
• The carcass and side connection profiles included in the set make it easier to design cabinet bodies with overlaying cabinet fronts. The top track and base profile also make for easier installation as they are fitted to the cabinet carcass from the front. They can also be fitted retrospectively across a number of previously installed cabinet carcass, consult manufacturer for further details.
• LGA certified.
• Sets with a track length of 2120 mm also make three door cabinet fronts possible in combination with Hawa Concepta, consult manufacturer for details.
• A wide range of components are available, consult manufacturer's literature for chosen variant.
