Haven Carpet Tile Collection: Familiar Comfortworx Tile C006W
Verified by manufacturer 1 year ago
35210
35210
M1 emission classification
Certificate type
Carpet tile, with a polymer modified bitumen backing.
Application
Recommended installation methods (product specific):
- Brick; Ashlar; Monolithic; Herringbone; Stagger.
Description
Carpet tile with a polymer modified bitumen backing, available in 12 colours.
Featured and benefits:
- Use classification 33 Commercial Heavy EN1307.
- Multi-level pattern loop, Eco Solution Q 100% solution dyed fibre.
- Cradle to Cradle™ Bronze Certified and EPD available.
- 15-year commercial limited warranty.
- We want it back: At the end of its useful life, we’ll reclaim and recycle or reuse our carpet tiles through our reTURN scheme
- Adhesive-Free Installation: IOBAC MagTabs™
General information
Color | Gold Blue Green Red |
Material | Nylon |
Shape | Rectangle |
Length | 1000 mm |
Width | 250 mm |
Height | 12.3 mm |
Warranty description | 15 year |
Uniclass | |
CAWS | M50/15 Carpet tiling M50/130 Carpet tiling |
SKU Code | C006W |
Specification data - Pile carpet tiles
Classification data | |
Style | Tufted 1/10", 39.4 per 100 mm. |
Material | Eco Solution Q® Polyamide 6. |
Classification | |
Standard | To BS EN 1307. |
Third-party certification | Cradle to Cradle: Bronze. Indoor air quality: A+ and Environmental product declaration. |
Level of use class | To BS EN 1307, class 33. |
Luxury rating class | LC1. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 25% (eco solution q® polyamide 6). |
Size | 1000 x 250 mm. |
Colour and pattern | Golden. |
Dye method | 100% solution dyed. |
Primary backing | Pet non-woven. |
Secondary backing | Comfortworx® Tile, Matrix Pad Layer Contains 90% Recycled Content. |
Total thickness | 12.3 mm. |
Mass | 4404 g/m², (nominal total pile mass). |
Pile density | To ISO 8543, 0.113 g/m³. |
Dimensional stability | To EN 986, ≤0.2%. |
Sound insulation | To ISO 10140, 36 dB. |
Sound absorption | To ISO 354/11654, 35 αw (Class D). |
Thermal resistance | 0.166 m² K/W. |
Colour fastness | >6. |
FlammabilityRating | To EN 13501-1, Bfl-S1 (adhered testing). |
Castor chair rating | To EN 985, ≥2.4. |
Light reflectance | 29.7. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | Manufacturer guidancere[TURN] TakeBack scheme. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 25 % Guidance for specification option: Eco Solution Q® Polyamide 6. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Product certifications
M1 emission classification
M1 Certificate
