Gx Backpainted Glass
Description

A range of metallic or sparkle finish back painted glass which is a popular choice for wall cladding and kitchen splash backs. Gx Back Painted is toughened as standard (annealed glass is available on request) and meets British Glazing Standards.

Gx Backpainted is Gx Glass' metallic and sparkle backpainted flat glass range - modern, hard-wearing and glamorous, it provides a bespoke design solution suited for commercial, contract and domestic interior glass applications, from wall cladding to splash backs to furniture tops.

Gx Backpainted allows you the flexibility to supply your own metallic or sparkle colour from established colour systems.

The paint has been extensively tested for both adhesion and longevity and Gx Back painted comes with a one year warranty for commercial and contract projects when installed by Gx Glass. Gx can be manufactured with cut outs and holes and be CNC or water jet shaped to drawings or rigid templates (subject to manufacturing tolerances). Gx Glass produces glass to British and European standards strength and flexibility in accordance with BS EN 12150 and safety up to BS EN 12600 Class 1.

General information

Size

[Size, Minimum: Annealed: 50 x 50 mm (smaller sizes are available on request for infills which are hand polished); Toughened: 100 x 220 mm; Maximum: Annealed: 1700 x 3150 mm, Toughened: 1730 x 3150 mm]

-

Uniclass 2015

Pr_25_71_33_88 Thermally toughened glass sheetsPrimary

CAWS

K13/160 Proprietary

L40/530 Internal tape glazing

L40/90 Internal tape glazing

Specification data - Thermally toughened glass sheets

Product Reference

Gx Back Painted Glass

Processing

Annealed

Toughened

Standard.

Type

Float

Slight green hue.

Low iron

Standard.

Thickness

4 mm

10 kg/m².

6 mm

Standard, 15 kg/m².

8 mm

20 kg/m².

10 mm

25 kg/m².

12 mm

30 kg/m².

15 mm

37.5 kg/m², not available in black.

19 mm

47.5 kg/m², not available in toughened or black.

Colour

Insert requirement.

Edges

Polished with painted edge and back arris

Standard.

Polished with painted back arris only

Clear edge and back arris

For glass tops and furniture.

Product Options

Size:

  • Minimum: Annealed: 50 x 50 mm (smaller sizes are available on request for infills which are hand polished); Toughened: 100 x 220 mm.
  • Maximum: Annealed: 1700 x 3150 mm, Toughened: 1730 x 3150 mm.
