GROHE Rapido SL
Description

Element for urinal with infra-red electronic control, for use with GROHE Rapido U.

Features:

  • Height adjustable for 1.13 and 1.30 m installation heights.
  • For manual actuation or Tectron infra-red electronic 6 V or 230 V control.
  • Can be used for on-the-wall installation or on studded walls.
  • PE-outlet bend, 50 mm diameter.
  • Includes fixing bolts M8 with fixing device.
  • Designed to hold up to 150 kg.
  • Inlet connection and inlet connect set supplied.
  • With stop valve.
  • Water supply connections 1/2" outer thread.
  • Connection box for mains supply.
  • Installation box with gasket.
  • Inspection shaft including protection during the construction phase.

General information

Features

Height adjustable for 1.13 and 1.30 m installation heights

For manual actuation or Tectron infra-red electronic 6 V or 230 V control

Can be used for on-the-wall installation or on studded walls

PE-outlet bend, 50 mm diameter

Includes fixing bolts M8 with fixing device

Designed to hold up to 150 kg

Inlet connection and inlet connect set supplied

With stop valve

Water supply connections 1/2" outer thread

Connection box for mains supply

Installation box with gasket

Inspection shaft including protection during the construction phase

Uniclass 2015

Pr_40_20_93_87 WC cistern fittingsPrimary

CAWS

N13/10 WC pans and flushing arrangements

N13/300 WCs and cisterns

N13/316 Urinals and flushing valves

Specification data - WC cistern fittings

Product Reference

GROHE Rapido SL, 38786001

Standard product features

Flow pressure:

0.5 bar (minimum).

Operating pressure:

10 bar (maximum).
