Grid Acoustic Ceiling Lattice

Verified by manufacturer 6 months ago

GRIW - Waves

Allsfar Variant:
Third party certifications:
  • EPD

    EPD

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • ISO 45001 Health and Safety Management

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • Made in Britain

    Made in Britain

    Certificate type

Acoustic ceiling lattices.

Jump to:
BIM object icon
+44 (0)20 3889 9888 Website

Application

Suitable for commercial interiors including offices and co-working spaces.

Description

Acoustic ceiling lattices designed and created by Allsfar's in-house designers. The variety of designs, shapes and colours provides creative flexibility and Allsfar's in-house CNC machine means prototypes can be created quickly before going into full-scale production.


Features and benefits:

  • 12 mm PET felt.
  • Made from 60% recycled PET.
  • No formaldehyde binders.
  • Low VOCs.
  • Created in-house delivering fast lead times and complete creative control.
  • The range of designs provides visual interest to ceilings.
  • Not affected by moisture, mould or mildew.
  • Easily retro-fitted to ceilings.
  • Suspension kit included.

General information

Color

Beige

Black

Blue

Brown

Green

Show more

Material

Polyester fibre (PET)

Shape

Rectangle

Oval

Other

Length

1360 mm

2400 mm

3650 mm

Width

1200 mm

1360 mm

1752 mm

Height

300 mm

385 mm

Warranty description

Five year

Uniclass

Ss_30_25_22_01 Acoustic baffle suspended ceiling systemsPrimary

CAWS

K45/160 Board-suspended ceiling system alterations

K45/120 Existing suspended ceiling system

K45/12 Existing suspended ceiling system

K40/265 Infill units

K40/115 Unit/ modular suspended ceiling system

K40/105 Suspended ceiling system

K40/10 Unit/ modular suspended ceilings

Specification data - Acoustic baffle suspended ceiling systems

System performance

Reaction to fire: To EN 13501-1:2007+a1:2009, B-s1, d0. To ASTM E84 -16, Class A

Ceiling support

Suspension kit.

1.5 m suspension wires included with each lattice.

Ceiling units

Acoustic ceiling lattices.

System accessories

None.

SUSCC-Suspended ceiling grid clip, M6.

Colour

Dual colours are available on all products.

Rosella red.

Rosella red fleck.

Oriole orange.

Oriole orange fleck.

Flamingo pink.

Show more

Dimensions

2400 x 1200 x 300 mm.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0.45 kg CO₂ eq/kg

Recyclability

Recyclable at end of life.

PET is 100% recyclable at end of life

Recycled content

60 %

Made from 60% recycled PET.

EPD

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
