Global Change - Carpet Tile
Description

Tufted patterned structured tiles pairing nature inspired design with the structure of a modular system. This collection comprises seven carpet tile ranges in both squares and skinny planks, ranging from organic to crisp designs.

Features:

  • Six colourways available within each collection.
  • Émissions dans l'air intérieur A+ rating.
  • CE marked to BS EN 1307.
  • Compatible with TacTiles™ glue-free installation system.

General information

Features

Six colourways available within each collection

Émissions dans l'air intérieur A+ rating

CE marked to BS EN 1307

Compatible with TacTiles™ glue-free installation system

Material

100% recycled solution dyed nylon, contains recycled content

Size

Glazing, Progression I, Progression II and Shading: 250 x 1000 mm

Ground, Progression III and Raku: 500 x 500 mm

Uniclass 2015

Pr_35_57_11_62 Pile carpet tilesPrimary

CAWS

M50/130 Carpet tiling

M50/15 Carpet tiling

Specification data - Pile carpet tiles

Product Reference

Glazing

6.7 mm thick.

Ground

7 mm thick.

Progression I

9.6 mm thick.

Progression II

7 mm thick.

Progression III

6.8 mm thick.

Raku

8.7 mm thick.

Shading

11 mm thick.

Colour

Insert requirement from 'Options' below.

Standard product features

Type:

  • Progression I, Raku and Shading: Tapestry tufted patterned structured tip sheared tile.
  • Progression II: Tufted patterned structured tip sheared tile.
  • Glazing, Ground and Progression III: Tufted patterned structured loop tile.

Material:

100% recycled solution dyed nylon, contains recycled content.

Size:

  • Glazing, Progression I, Progression II and Shading: 250 x 1000 mm.
  • Ground, Progression III and Raku: 500 x 500 mm.

Thickness:

  • Pile height: Glazing: 3.9 mm (+15%/ -10%); Ground and Progression III: 3.6 mm (+15%/ -10%); Flagstone: Progression I: 5.3 mm (+15%/ -10%); Progression II: 3.3 mm (+15%/ -10%); Raku: 4.2 mm (+15%/ -10%); Shading: 4.6 mm (+15%/ -10%).
  • Total: Glazing: 6.7 mm (±0.5 mm); Ground and Progression II: 7 mm (±0.5 mm); Progression I: 9.6 mm (±0.5 mm); Progression III: 6.9 mm (±0.5 mm); Raku: 8.7 mm (±0.5 mm); Shading: 11 mm (±0.5 mm).

Weight:

  • Pile yarn: Glazing, Ground and Progression III: 644 g/m² (±5%); Progression I: 1050 g/m² (±5%); Progression II: 576 g/m² (±5%); Raku: 1017 g/m² (±5%); Shading: 983 g/m² (±5%).
  • Total: Glazing: 4088 g/m² (±5%); Ground: 4120 g/m² (±5%); Progression I: 4580 g/m² (±5%); Progression II: 4038 g/m² (±5%); Progression III: 4805 g/m² (±5%); Raku: 4610 g/m² (±5%); Shading: 4610 g/m² (±5%).

Backing:

Graphlex®.

Method of laying:

  • Ground: Brick or quarter-turn.
  • Glazing, Progression I, Progression II, Progression III and Shading: Ashlar or herringbone.
  • Raku: Ashlar, brick, monolithic, non-directional or quarter-turn.

Technical properties:

- Glazing:

  • Tufts per m²: 184 080 (±5%).
  • Wear classification (to BS EN 1307): Class 33/ LC2 Heavy Contract.
  • Gauge/ ends 10 cm: 1/12 – 47.2.
  • Radiant panel (to BS EN ISO 9239-1): Euroclass Bfl-s1 (to BS EN 13501-1).
  • Dimensional stability (to BS EN 986): ≤0.2%.
  • Impact sound insulation ΔLw (to BS EN ISO 10140-3): 26 dB.
  • Sound absorption rating (αw, to BS EN ISO 11654): 0.2.
  • Sound absorption coefficient (to BS EN ISO 354): 125 Hz: 0.02; 250 Hz: 0.03; 500 Hz: 0.08; 1000 Hz: 0.19; 2000 Hz: 0.32; 4000 Hz: 0.40.
  • Castor chair rating (to BS EN 985): ≥2.4.
  • Colour fastness - Light (to ISO 105/B02): 7.

- Ground and Progression III:

  • Tufts per m²: 202 960 (±5%).
  • Wear classification (to BS EN 1307): Class 33/ LC2 Heavy Contract.
  • Gauge/ ends 10 cm: 1/12 – 47.2.
  • Radiant panel (to BS EN ISO 9239-1): Euroclass Bfl-s1 (to BS EN 13501-1).
  • Dimensional stability (to BS EN 986): ≤0.2%.
  • Impact sound insulation ΔLw (to BS EN ISO 10140-3): 26 dB.
  • Sound absorption rating (αw, to BS EN ISO 11654): 0.2.
  • Sound absorption coefficient (to BS EN ISO 354): 125 Hz: 0.02; 250 Hz: 0.03; 500 Hz: 0.08; 1000 Hz: 0.19; 2000 Hz: 0.32; 4000 Hz: 0.40.
  • Castor chair rating (to BS EN 985): ≥2.4.
  • Colour fastness - Light (to ISO 105/B02): 7.

- Progression I:

  • Tufts per m²: 169 420 (±5%).
  • Wear classification (to BS EN 1307): Class 33/ LC3 Heavy Contract.
  • Gauge/ ends 10 cm: 1/10 – 39.4.
  • Radiant panel (to BS EN ISO 9239-1): Euroclass Bfl-s1 (to BS EN 13501-1).
  • Dimensional stability (to BS EN 986): ≤0.2%.
  • Impact sound insulation ΔLw (to BS EN ISO 10140-3): 29 dB.
  • Sound absorption rating (αw, to BS EN ISO 11654): 0.2.
  • Sound absorption coefficient (to BS EN ISO 354): 125 Hz: 0.01; 250 Hz: 0.04; 500 Hz: 0.12; 1000 Hz: 0.27; 2000 Hz: 0.41; 4000 Hz: 0.53.
  • Castor chair rating (to BS EN 985): ≥2.4.
  • Colour fastness - Light (to ISO 105/B02): 7.

- Progression II:

  • Tufts per m²: 169 420 (±5%).
  • Wear classification (to BS EN 1307): Class 33/ LC1 Heavy Contract.
  • Gauge/ ends 10 cm: 1/10 – 39.4.
  • Radiant panel (to BS EN ISO 9239-1): Euroclass Bfl-s1 (to BS EN 13501-1).
  • Dimensional stability (to BS EN 986): ≤0.2%.
  • Impact sound insulation ΔLw (to BS EN ISO 10140-3): 25 dB.
  • Sound absorption rating (αw, to BS EN ISO 11654): 0.2.
  • Sound absorption coefficient (to BS EN ISO 354): 125 Hz: 0.01; 250 Hz: 0.05; 500 Hz: 0.08; 1000 Hz: 0.22; 2000 Hz: 0.34; 4000 Hz: 0.44.
  • Castor chair rating (to BS EN 985): ≥2.4.
  • Colour fastness - Light (to ISO 105/B02): 7.

- Raku:

  • Tufts per m²: 153 660 (±5%).
  • Wear classification (to BS EN 1307): Class 33/ LC3 Heavy Contract.
  • Gauge/ ends 10 cm: 1/10 – 39.4.
  • Radiant panel (to BS EN ISO 9239-1): Euroclass Bfl-s1 (to BS EN 13501-1).
  • Dimensional stability (to BS EN 986): ≤0.2%.
  • Impact sound insulation ΔLw (to BS EN ISO 10140-3): 29 dB.
  • Sound absorption rating (αw, to BS EN ISO 11654): 0.2.
  • Sound absorption coefficient (to BS EN ISO 354): 125 Hz: 0.01; 250 Hz: 0.04; 500 Hz: 0.12; 1000 Hz: 0.27; 2000 Hz: 0.41; 4000 Hz: 0.53.
  • Castor chair rating (to BS EN 985): ≥2.4.
  • Colour fastness - Light (to ISO 105/B02): 7.

- Shading:

  • Tufts per m²: 169 420 (±5%).
  • Wear classification (to BS EN 1307): Class 33/ LC3 Heavy Contract.
  • Gauge/ ends 10 cm: 1/10 – 39.4.
  • Radiant panel (to BS EN ISO 9239-1): Euroclass Bfl-s1 (to BS EN 13501-1).
  • Dimensional stability (to BS EN 986): ≤0.2%.
  • Impact sound insulation ΔLw (to BS EN ISO 10140-3): 29 dB.
  • Sound absorption rating (αw, to BS EN ISO 11654): 0.2.
  • Sound absorption coefficient (to BS EN ISO 354): 125 Hz: 0.01; 250 Hz: 0.04; 500 Hz: 0.12; 1000 Hz: 0.27; 2000 Hz: 0.41; 4000 Hz: 0.53.
  • Castor chair rating (to BS EN 985): ≥2.4.
  • Colour fastness - Light (to ISO 105/B02): 7.

Product Options

Colour:

- Glazing:

9079001 Daylight, 9079002 Desert shadow, 9079003 Evening dusk, 9079004 Morning mist, 9079005 Fawn, 9079006 Eclipse.

- Ground:

9083001 Daylight, 9083002 Desert shadow, 9083003 Evening dusk, 9083004 Morning mist, 9083005 Fawn, 9083006 Eclipse.

- Progression I:

9080001 Daylight, 9080002 Desert shadow, 9080003 Evening dusk, 9080004 Morning mist, 9080005 Fawn, 9080006 Eclipse.

- Progression II:

9082001 Daylight, 9082002 Desert shadow, 9082003 Evening dusk, 9082004 Morning mist, 9082005 Fawn, 9082006 Eclipse.

- Progression III:

9081001 Daylight, 9081002 Desert shadow, 9081003 Evening dusk, 9081004 Morning mist, 9081005 Fawn, 9081006 Eclipse.

- Raku:

8334001 Daylight, 8334002 Desert shadow, 8334003 Evening dusk, 8334004 Morning mist, 8334005 Fawn, 8334006 Eclipse.

- Shading:

8335001 Daylight, 8335002 Desert shadow, 8335003 Evening dusk, 8335004 Morning mist, 8335005 Fawn, 8335006 Eclipse.
