Glide-On Aluminium Cassette Balcony

Application

Suitable for residential buildings.

Description

Glide-On™ aluminium Cassette® balconies, with Crystal® frameless structural glass on the front with Crystal® frameless structural glass on the left and with Crystal® frameless structural glass on the right


Features and benefits:

  • Discreet fixings and pre-fitted soffits,
  • Offers numerous benefits over ‘traditional’ balconies including, offsite construction, speedy installation, increased tolerance, and improved rigidity.

General information

Color

Grey

Finish

Powder coated

Material

Aluminium

Glass

Shape

Rectangle

Size

3500 x 1500 mm.

Useable area is 5.25 m², outside area is 5.69 m².

WarrantyDescription

Rigid. Ready. Right. Brand Promise. Our commitment includes a three-fold promise that every balcony we produce will be Rigid, Ready and Right.

Uniclass 2015

Ss_25_60_05_05 Balustrade and guarding systemsPrimary

CAWS

L30/560 Proprietary balustrades

L30/55 Proprietary balustrades

Specification data - Balustrade and guarding systems Enhanced data

Infills

Frameless structural glass formed of two panels of toughened 10 mm glass laminated together with 1.5 mm clear PVB interlayer, mechanically fixed to Cassette.

Rails

-

Handrails

Toprail - 27 x 27 mm square polyester powder coated aluminium capping, light grey.

Fixing to parent structure

Cast-in balcony anchor, preassembled with thermal breaks and concrete edge casting shutter.

Samples required

Product samples

Arms

Two piece galvanized steel arms.

Decking

WPC composite decking fixed with hidden clips, boards in S1 Old Mahogany Brown with grooved finish.

Environmental information

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom
