Glendyne Canadian Natural Roofing Slate - Natural Roofing Slate
Verified by manufacturer 2 months ago
Glendyne Canadian Natural Roofing Slate - 406 x 254
Glendyne Canadian Natural Roofing Slate - 406 x 254
Natural roofing slate.
Application
Ideal for use on any major refurbishment or new build project including:
- Supermarkets.
- Schools.
- City offices.
- Prestige homes.
- Heritage buildings.
- Grade II buildings.
Description
Glendyne slate is produced in Saint Marc du Lac Long, Quebec, Canada. The slate is high quality due to the exceptional slate deposit and the combination of modern extraction technology with traditional finishing skills.
Features and benefits:
- Glendyne slate will withstand the most severe weather conditions: it is unaffected by sunlight, ultraviolet light and even acid rain.
- Laid correctly, Glendyne slate will last the lifetime of the building.
- The product can be reused after primary installation.
Glendyne slates must be laid in accordance with the Code of Practice for Slating and Tiling, BS 5534 and the Code of Practice for Workmanship on Building Sites – Slating and Tiling, BS 8000.
General information
Color | Grey |
Material | Slate |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
WarrantyDescription | 75 year |
Uniclass | |
CAWS | H62/3 Roof slating H62/105 Roof slating |
Specification data - Natural slates
Slate type | - |
Source | Quebec.Saint Marc du Lac Long, Quebec, Canada. |
Colour | Blue/ Grey. |
Slate size | - |
Length (minimum) | 406 mm. |
Width (minimum) | 254 mm. |
Standards | - |
Product specification | To BS EN 12326-1. |
Methods of test | To BS EN 12326-2. |
Properties | - |
Type | Flat. |
Dimensional tolerances | 1%. |
Nominal thickness and individual thickness variation | 5—6 mm. |
Characteristic modulus of rupture (Transverse) | 52 Mpa. |
Characteristic modulus of rupture (Longitudinal) | 60 Mpa. |
Mean failure load (Transverse) | 64 Mpa. |
Mean failure load (Longitudinal) | 75 Mpa. |
Water absorption | 0.30%. |
Thermal cycle test | Code T1.To BS EN 12326-1. |
Carbonate content | 0.30% |
Sulfur dioxide exposure test | Code S1.To BS EN 12326-1. |
Non-carbonate carbon content (maximum) | 0.60%. |
Weight | 1.42—2.65 kg. Dependent on variant specified. |
Head-lap | 98 mm. |
Battens | 154 mm. |
Roof pitch | 30˚. |
Coverage | 12.81—25.56 m², dependent on variant specified. |
Total weight | 33.6—36.3 kg, dependent on variant specified. |
Environmental information
Contains Red List materials | No |
Country of material origin | Canada |
Country of product manufacture | Canada |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 0.05 kg CO₂ eq/kg |
Recyclability | Yes |
Recycled content | 100 % |
BIM objects
NBS BIM object standard
This BIM object has been authored to meet the requirements of the NBS BIM object standard.
Find out more about the NBS BIM object standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
Glendyne_Slates_Warranty_SPECIMEN
Glendyne_Product_Brochure_2021_Web
GLENDYNE_TECH_DATA_WITH_DRAWINGS
Glendyne COSHH Datasheet
