This product is no longer available —

GetaLit® Kompakt Sheet
Application

For indoor use.

See manufacturer's literature for details on stains, dirt and similar surface defects.

Description

Decorative and compact high-pressure laminate (HPL) sheet, manufactured in accordance with DIN EN 438.

Features and benefits:

  • Flame retardant (according to DIN 4102-1 and DIN EN 13501-1).
  • Food safe (according to EN 1186 and EN 13130).
  • Steam, impact, heat, abrasion and scratch resistant (according to DIN EN 438).
  • Resistant to common household chemicals.
  • Light-fast (according to EN 438).
  • Anti-bacterial (according to JIS Z 2801).
  • FSC® certification available on request.

Components (from top to bottom):

  • Overlay.
  • Decor paper.
  • Kraft papers.
  • Decor paper.
  • Overlay.

Applications:

For indoor use.

See manufacturer's literature for details on stains, dirt and similar surface defects.

General information
Uniclass 2015
Pr_25_71_94_37 High-pressure decorative laminates (HPL or HPDL)Primary
CAWS

K13/130 Laminated plastics-veneered panel lining

Specification data - High-pressure decorative laminates (HPL or HPDL)
Product Reference

GetaLit® Kompakt Sheet, Type CGF

Length

Consult manufacturer and insert requirements.

Width

Consult manufacturer and insert requirements.

Thickness

2–20 mm (brown core), 2–12 mm (black core). Consult manufacturer for details and insert requirements.

Colour/ Finish

Consult manufacturer's literature and insert requirements.

Standard product features

Fire behaviour (to DIN 4102-1):

B1 (flame retardant).

Technical characteristics:

  • Vapour resistance (DIN EN 438-2): ≥ a moderate change in gloss level and/ or colour.
  • Stain resistance (DIN EN 438-2): ≥ a moderate change in gloss level and/ or colour.
  • Impact resistance (DIN EN 438-2): >1400 mm (at 2–6 mm), >1800 mm (at >6 mm).
  • Heat resistance (DIN EN 438-2): ≥ a moderate change in gloss level and/ or colour.
  • Light fastness (to DIN EN 438-2): Grey scale 4–5.
  • Abrasion resistance (to DIN EN 438-2): ≥ a moderate change in gloss level and/ or colour (decor related deviations are possible).
  • Scratch resistance (to DIN EN 438-2): Moderate change in gloss level and/ or colour (≥2 N, or ≤2 N for gloss and perlmatt surfaces).
  • Modulus of elasticity (to EN ISO 178): ≥9000 MPa.
  • Bending strength (to EN ISO 178): ≥80 MPa.
  • Raw density (to EN ISO 1183-1): ≥1350 kg/m³.
  • Antibacterial (to JIS Z 2801): 99.9% of bacteria is destroyed after 24 hours.

Product Options

Length/ width:

Allow +10 mm (basic range). Consult manufacturer for information on cut-to-size sheet deviations.
