FUEGO Light Rebated Glazed Door

Verified by manufacturer 2 months ago

FUEGO Light Rebated Glazed Door - EI30

Forster Profile Systems (UK) Ltd Variant:

Fire resistant, rebated door.

Jump to:
+44 (0)1909 295000 Website

Application

Fire resistant door, for internal use in a range of applications offering fire and smoke protection without compromising on design.

Description

Glazed fire-resistant rebated doors with lever handles offering a range of fire performance options.

Fully tested and approved, extensive profile system with fittings and accessories for single and double leaved glazed fire resistant doors. The appeal of the system resides in the extremely slender visible profile widths, the overall filigree look and great transparency. More light, more clarity, more safety for modern appearance.


Features and benefits:

  • Aesthetically pleasing sightlines.
  • Incorporation of sidelights and fanlights.
  • Slender appearance.
  • Ease of use for either leaf operation.
  • Very slender visible section widths, outer frame/ leaf measurement of only 110 mm.
  • Fittings to match the system and concealed hinges.
  • Beautifully styled stainless steel handle fittings and a wide range of standard weld-on and screw-mounted rolling hinges.
  • Concealed invisible door-closing systems.
  • Prefabricated profiles for efficient processing, including assembly of the concealed door-closers.

General information

Color

Other

Finish

Powder-coated

Material

Steel

Stainless steel

Shape

Rectangle

Width

1400 mm

1340 mm

1250 mm

Height

3000 mm

2900 mm

2700 mm

2500 mm

Warranty description

-

Manufacturer guidance

Consult manufacturer and insert requirements.

Uniclass

Pr_30_59_24_52 Carbon steel doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

Specification data - Carbon steel doorsets

Third-party certification

-

Manufacturer guidance

Available on request, consult manufacturer for details.

Configuration

Single leaf.

Double leaf.

Doorset size

1400 x 3000 mm.

Manufacturer guidance

Clear opening maximum single leaf: (W×H).

Performance

-

Fire resistance

-

Integrity

30 minutes.

Insulation

30 minutes.

Radiation

30 minutes.

Smoke leakage

yes.

Acoustic performance

42 dB.

Frame

-

Material

Steel.

Threshold

Barrier free.

Perimeter seals or inserts

As standard.

Finish

-

Coating

Powder-coated.

Door leaf

-

Thickness

65 mm.

Glazing

-

Type

-

Manufacturer guidance

Consult manufacturer and insert requirements.

Finish

-

Coating

Powder-coated.

External colour

Powder-coated.

Internal colour

Powder-coated.

Hardware

Lever Handles.

Push bar.

Accessories

Not required.

Door closer.

Maglocks.

Door automation.

Size

-

Manufacturer guidance

Consult manufacturer and insert requirements.

Sustainability data

Country of material origin

Europe

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

17 %
