FRAME+ 100/120 RI Rooflight - Rooflight Window System

Rooflight window system, available with or without interior timber cladding.

Available in two variants and a range of system types, including as top hung, or as a turn or tilt window. A range of profiles are available dependent on project requirements.

Features and benefits:

- FRAME⁺ 100/120 RI:

• Innovative insulating bar material THERMORIT with very low thermal conductivity and suitable for composite coating and anodizing.
• Stepped glass variant optionally available either in unilateral design or with circumferential full glass finish with identical outer and sash frame.
• Various glass step variants available for a circumferential glass step (F-strip, suction disc).
• Two different glazing variants due to the option for the screw connection of the cover profile (visible or concealed).
• High degree of tightness by three peripheral seal levels with medial gasket frame.
• First Passive House certified.

- FRAME⁺ 100/120 RI-T:

• Aluminium timber window with identical processing technology of standard aluminium windows.
• Real wood cladding on the inside as a decorative element, perfectly suited to the optical appearance of the curtain wall; wide range of different types of wood.
• Real wood cladding on the inside with simple screw connection technique on production or construction site, exchangeable after installation.
• Integral sash made of dimensionally stable aluminium-THERMORIT composite construction without considering the interior timber frame, therefore exchangeable at any time.
• Compensation of glass infill thickness by special clip gaskets.
