Focus F

Application

For applications requiring a ceiling which is mechanically secured to the structural soffit.

Description

For applications where the minimum possible overall depth of system is required. The tiles are bonded edge-to-edge directly to the soffit surface, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile. The tiles are not demountable.

Ecophon recommends Connect screws for a quick and secure installation.

Features and benefits:

  • The tiles are manufactured from high-density glass wool.
  • The visible surface has an Akutex™ FT coating, and the back of the tile is covered with glass tissue.
  • The edges are reinforced and painted.
  • The weight is approximately 2.5 kg/m².

General information

Color

White

Features

Installed directly to an existing plaster ceiling, boarding, battens or concrete, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove

Finish

Akutex FT – the surface allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool, providing optimum sound absorption. Reinforced and painted edges

Material

High-density glass wool

Shape

Square

Rectangular

Size

600 x 600 mm

1200 x 600 mm

WarrantyDescription

Full warranty available upon request

Uniclass 2015

Ss_30_25_22_70 Raft or island suspended ceiling systemsPrimary

CAWS

K40/10 Suspended ceilings

K40/105 Suspended ceiling system

K40/115 Unit/ modular suspended ceiling system

K40/265 Infill units

K45/12 Existing suspended ceiling system

K45/120 Existing suspended ceiling system

K45/160 Board-suspended ceiling system alterations

Specification data - Raft or island suspended ceiling systems Enhanced data

Ceiling support

Direct fix to soffit.

Support fasteners

Connect™ screws.

Ceiling type

Direct fix to soffit.

System accessories

None

Connect™ Angle Trim C1

White (wall to wall ceiling).

Connect™ Wood Trim

White (floating ceiling).

Product Reference

Focus F

Panel size (l x w)

600 x 600 mm.

1200 x 600 mm.

Thickness

20 mm.

Colour/ Finish

White Frost.

White 500, Nearest NCS colour sample S 0500-N, 85% light reflectance (of which more than 99% is diffuse reflection). Retro reflection coefficient 63 mcd/(m2lx). Gloss < 1.

Weight

2.5 kg/m².

approximate, including grid

Demounting depth (minimum)

20 mm.

Indoor climate

Recommended by the Swedish Asthma and Allergy Association. Certified as A+ by French VOC. Emission classification of building materials: M1.

Moisture resistance

Class A, relative humidity 70% and 25°C, according to EN 13964:2014.

Fire safety

To BS EN 13501-1, Class A2-s1, d0.

Sound absorption

To EN ISO 11654, Class C.

Cleaning

The ceiling system can withstand daily dusting and vacuum cleaning, and weekly wet-wiping.

Environmental information

Contains Red List materials

All Ecophon products are free from substances of very high concern (SVHC) and any compound on the list of REACH in the EU.

-

Country of material origin

Sweden, Finland or Poland.

Sweden

Embodied carbon

4.58 kg CO₂ equiv/m², in conformity with ISO 14025/ EN 15804

Recycled content

52
