Application

For applications where the minimum possible overall depth of system is required.

Description

For applications where the minimum possible overall depth of system is required. The tiles are bonded edge-to-edge directly to the soffit surface, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile. The tiles are not demountable.

Ecophon recommends Connect Absorber Glue for a quick and easy installation.

Features and benefits:

  • The tiles are manufactured from high-density glass wool.
  • The visible surface has an Akutex™ FT coating, and the back of the tile is covered with glass tissue.
  • The edges are painted.
  • The weight is approximately 2.5 kg/m².

Application:

For applications where the minimum possible overall depth of system is required.

General information
Features

The tiles are bonded edge-to-edge directly to the soffit surface, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile

Finish

Akutex FT – the surface allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool, providing optimum sound absorption. Painted edges

Material

High-density glass wool

Shape

Square

Size

600 x 600 mm (l x w), 40 mm thickness

WarrantyDescription

Full warranty available upon request

Uniclass 2015 Raft or island suspended ceiling systems (Ss_30_25_22_70)
Specification data
Product Reference

Focus B

Ceiling support

Direct fix to soffit

Support fasteners

Connect™ Absorber Glue

Ceiling units

Direct fix to soffit

System accessories

None

Connect™ Angle Trim C1

White (wall to wall ceiling).

Connect™ Wood Trim

White (floating ceiling).

Colour/ Finish

Cloudy Day

Nearest NCS colour sample S 1500-N, 62% light reflectance.

Scallop Shells

Nearest NCS colour sample S 1515-Y80R.

Peach Rose

Nearest NCS colour sample S 1515-Y80R.

Goji Berry

Nearest NCS colour sample S 3030-Y80R.

Sage Garden

Nearest NCS colour sample S 3010-B30G.

Eucalyptus Leaf

Nearest NCS colour sample S 5010-B30G.

Summer Forest

Nearest NCS colour sample S 6030-G10Y.

Dark Diamond

Nearest NCS colour sample S 9000-N, 4% light reflectance.

Golden Field

Nearest NCS colour sample S 1040-G90Y, 61% light reflectance.

Highland Fog

Nearest NCS colour sample S 2005-G, 55% light reflectance.

Moonlight Sky

Nearest NCS colour sample S 7020-R90B, 7% light reflectance.

Morning Drizzle

Nearest NCS colour sample S 1002-B, 69% light reflectance.

Ocean Storm

Nearest NCS colour sample S 4020-R90B, 24% light reflectance.

Ruby Rock

Nearest NCS colour sample S 4050-R10B, 7% light reflectance.

Silent Steam

Nearest NCS colour sample S 2010-B, 45% light reflectance.

Silk Slate

Nearest NCS colour sample 7000-N, 13% light reflectance.

Silver Stone

Nearest NCS colour sample S 4502-Y, 29% light reflectance.

Sunset Heat

Nearest NCS colour sample S 2070-Y60R, 20% light reflectance.

Volcanic Ash

Nearest NCS colour sample 2002-Y, 56% light reflectance.

White Frost

Standard. White 500, Nearest NCS colour sample S 0500-N, 85% light reflectance (of which more than 99% is diffuse reflection). Retro reflection coefficient 63 mcd/(m2lx). Gloss <1.

Weight

2.5 kg/m² (approximate including grid)

Overall depth of system (minimum)

23 mm

Indoor climate

Recommended by the Swedish Asthma and Allergy Association. Certified as A+ by French VOC. Emission classification of building materials: M1

Moisture resistance

Class A, relative humidity 70% and 25°C, according to EN 13964: 2014

Fire safety

Complies with BS EN 13501-1, Class A2-s1, d0

Sound absorption

In accordance with EN ISO 11654, Class C

Cleaning

The ceiling system can withstand daily dusting and vacuum cleaning, and weekly wet-wiping

Standard product features

Colour:

Wide range available.

Features:

The tiles are bonded edge-to-edge directly to the soffit surface, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile.

Finish:

Akutex FT – the surface allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool, providing optimum sound absorption. Painted edges.

Material:

High-density glass wool.

Shape:

Square.

Size:

600 x 600 mm (l x w), 40 mm thickness.

Warranty description:

Full warranty available upon request.

Recycled content:

>52%.

Embodied carbon:

4.59 kg CO₂ equiv/m², in conformity with ISO 14025/ EN 15804.

Red Listed materials:

All Ecophon products are free from substances of very high concern (SVHC) and any compound on the list of REACH in the EU.

Country of origin:

Sweden, Finland or Poland.

Environmental information
Embodied carbon

4.59 kg CO₂ equiv/m², in conformity with ISO 14025/ EN 15804

Recycled content

>52%
