Flush Sash Window 70 mm

Liniar

PVC-U flush sash windows.

Jump to:
+44 (0)1332 883900 Website

Application

  • For residential applications.
  • Particularly suitable for conservation areas.

Description

Energy efficient windows which make use of symmetrical multi-chambered PVC-U profiles, reducing unnecessary steel reinforcement. Flush sash windows are beaded internally or externally and offer a number of features and benefits in a range of styles. The slim frames increase the flow of natural light as well as creating an enhanced field of view - and with the sash fitting flush against the outer frame, replicate the appearance of pre-1932 timber windows.


Available in EnergyPlus six-chamber profile, offering Windows Energy Ratings up to A++ depending on glazing options, the range is available in a wide choice of colours and finishes from stock, with special colours available on longer lead times.


Features and benefits:

  • Patented co-ex bubble gasket.
  • Thermally efficient.
  • 100% lead-free PVC-U.
  • Easy to install.
  • Ten year profile guarantee.
  • Slim sightlines.
  • Replicates a pre-1932 timber window.

Accreditations:

  • Secured by Design approved.
  • PAS 24:2012 Kitemark 522039.
  • BS EN 12608:2003.

General information

Color

Green

Black

Grey

Brown

White

Show more

Material

PVC-U

WarrantyDescription

Ten year

Profile guarantee.

Uniclass

Pr_30_59_98_92 Unplasticized polyvinyl chloride (PVC-U) window unitsPrimary

CAWS

L10/30 PVC-U windows

L10/350 PVC-U windows

Specification data - Unplasticized polyvinyl chloride (PVC-U) window units

Third-party certification

PAS 24:2012 Kitemark 522039.

Product performance

-

Safety

-

Security level

To PAS 24.

To Secured by Design standard.

Thermal

-

British Fenestration Rating Council Window Energy Rating

Windows Energy Ratings up to A++ depending on glazing options. Consult manufacturer.

-

Frame

-

Colour and texture

7016 Grey.

Black.

Chartwell green.

Cream.

Cream foil.

Golden oak.

Irish oak.

Mahogany.

Rosewood.

White.

White foil.

Ventilator

Not required.

Head vent required.

30 mm.

Glazing or infill

-

Requirements

Double.

28 mm, U-Value of 1.3 W/m²K achievable, consult manufacturer.

Triple.

28 mm, U-Value of 0.9 W/m²K achievable, consult manufacturer.

Bead

External.

Optional.

Internal.

Standard.

Chamber

Six chamber profile - EnergyPlus 70 mm.

External sill

85 mm.

150 mm.

165 mm.

180 mm.

225 mm.

Glazing flipper

Creates a thermal barrier and additional gasket for even higher energy efficiency.

Not required.

Required.

Outer frame

57 mm.

77 mm.

Profile

(Frame profile)

Sculptured.

Thermal dam

Creates a multi-chambered barrier to prevent heat loss at the outer edge of the frame.

Not required.

Required.

Transom

67 mm.

87 mm.
