Floor Door Stainless Steel - 100 mm Recess - 125 kN - Lift Out or Hinged - SBVEH
Compare variants

Floor Door Stainless Steel - 100 mm Recess - 125 kN - Lift Out or Hinged - SBVEH

Verified by manufacturer 16 days ago

SBVEH-maxi - 125 kN - 102 mm Recess - Lift Out

Surespan Variant:

Stainless Steel floor access doors with 102 mm deep recess. Tapered design allows easy opening. Virtually invisible when installed. EPDM seal. Robust steel mesh reinforcement.

Jump to:
+44 (0)1922 711185 www.surespancovers.com

Application

Easy-to-open design accommodates a variety of flooring slabs, paviours and ceramic finishes.

Description

SBVEH range is manufactured from stainless steel grade 304 with an EPDM Seal. Available with infill depth of 102 mm.


Features and benefits:

  • Up to 125 kN test load (EN 124).
  • Available as Lift Out or hinged.
  • Sealed access cover in high-quality finish.
  • Complete with EPDM seal.
  • The cover is reinforced with a clamped steel mesh reinforcement.

General information

Shape

Rectangle

Square

Material

Steel

  • Frame and cover sections in stainless steel grade 304 (standard)/ 316 (on request).
  • Stainless steel screws.

Rubber

  • EPDM rubber seal.

Size

300 x 300 mm

400 x 400 mm

500 x 500 mm

600 x 400 mm

600 x 600 mm

Show more

Uniclass

Pr_65_52_01_02 Access covers, gratings and framesPrimary

CAWS

R12/54 Access points – plastics

L20/630 Hatches

R12/471 Access covers and frames

L20/60 Doors

P30/301 Access covers, manhole tops and frames

Specification data - Access covers, gratings and frames

Configuration

Lift out.

Finish

Self-finish.

Load class (minimum)

Not required.

125 kN.

Test load (per EN124) when filled with grade C35/45 Concrete (EN 206).

Frame or support

Stainless Steel Grade 304.

As standard.

Stainless Steel Grade 316.

On request.

Size:

300 x 300 mm.

400 x 400 mm.

500 x 500 mm.

600 x 400 mm.

700 x 700 mm.

Show more

FireRating

Not required.

Infill depth

102 mm.

Cover depth

125 mm.

CoverMaterial

Stainless Steel Grade 304.

As standard.

Stainless Steel Grade 316.

On request.

Hardware

Stainless steel screws.

Locking

  • SureCover SBVEH comes with a set of lifting keys and precise installation instructions.
  • Jammed covers are released by simply turning the Brass Key provided.

Seal

EPDM rubber.

Reinforcement

Steel mesh.
