Fire Rated 30-60-90 mins Spotlight, CCT, IP65, Triac Dimmable down light 10107DFV/W - Recessed COB LED Spotlight
Verified by manufacturer today
Recessed fire-rated COB LED spotlight.
Application
Recessed ceiling luminaire, indoor or outdoor use.
Description
Recessed fire-rated COB LED spotlight.
Features and benefits:
- Complies with EN 60598-1 and any other specific standards.
- Fire-rated, 90 minutes.
- IP65.
- Variable CCT: 2700 K - 3000 K - 4000 K.
- Output: 510 lumens.
- CRI: 80.
- Beam angle: 60°.
- Supplied with Triac dimmable LED driver.
- Supplied with a white ring as standard, optional black or chrome rings.
General information
Color | White Guidance for specification option: Standard. Black Silver Guidance for specification option: Chrome. Manufacturer guidanceOuter ring only. |
Material | Metal |
Shape | Circle |
Length | 88 mm |
Width | 88 mm |
Height | 73 mm |
Warranty description | Three year |
Uniclass | |
CAWS | V90/510 General purpose luminaires V90/510 Luminaires |
Specification data - Recessed luminaires
Standards | To EN 60598-1.Guidance for specification option: And any other specific standards; consult manufacturer for details. |
Luminaire description | Circular COB LED spot for installation in ceilings.Guidance for specification option: Requires 65 mm-diameter cut-out hole and 80 mm depth. |
Classification | |
Ingress protection (minimum) | IP65. |
Circumstances of use | Normal. |
Controlgear position | Integral within luminaire.Guidance for specification option: LED driver, IP20. |
Nominal voltage | 220–240 V a.c.Guidance for specification option: 50/ 60 Hz. |
LED luminaires | |
Initial LED luminaire efficacy (minimum) | 72.86 lm/W |
Wattage | 7 W. |
Colour temperature | Variable 2700 K; 3000 K; 4000 K. |
Colour rendering index (Ra) | 80. |
Beam angle | 60°. |
Dimming protocol | TRIAC.Guidance for specification option: Supplied with Triac dimmable LED driver. |
Accessories | None.Guidance for specification option: White ring as standard. 050178/B black ring.Guidance for specification option: Aluminium; replaces standard white ring. 050178/C chrome ring.Guidance for specification option: Aluminium; replaces standard white ring. |
Output | 510 lm. |
