Fire Exit Steel Doors - Double - AD10 Armourdoor

Verified by manufacturer 3 days ago

HAG Ltd. - The Door Specialists Third party certifications:
  • ADSA

    ADSA

    Certificate type

  • AkzoNobel

    Certificate type

  • Alcumus SafeContractor

    Alcumus SafeContractor

    Certificate type

  • Made in Britain

    Made in Britain

    Certificate type

  • CHAS

    CHAS

    Certificate type

  • Constructionline

    Constructionline

    Certificate type

  • dhf certificate

    dhf certificate

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • UK Conformity Assessed (UKCA)

    UK Conformity Assessed (UKCA)

    Certificate type

Fire exit double door constructed from 1.2 mm zinc-protected steel sheets with a choice of infill.

Jump to:
BOS
0800 072 3444 Website

Application

Fire exit steel doors suitable for industrial, commercial, residential, public buildings, hospitality and cultural or historical settings

  • Airports
  • Train stations
  • Kitchen servery hatches
  • Retail units
  • Shopping malls
  • Offices
  • Leisure complex
  • Warehouse
  • Factories
  • Chemical plant
  • Hospitals
  • Care homes
  • Receptions areas
  • Schools
  • Colleges
  • Academies
  • Universities
  • Nurseries
  • Residential - high rise or large houses
  • Hotels
  • Restaurants
  • Museums
  • Libraries
  • Historical sites

Description

Fire exit double door constructed from 1.2 mm zinc-protected steel sheets joined together in a bonding process with a choice of infill.


Features and benefits:

  • Infill: Choose from honeycomb core, rock wool, or solid timber dependent on insulation and security requirements.
  • Provides safe and effective escape through the doorway with minimal effort and without prior knowledge of operation.
  • The door is supported by a 1.6 mm profiled zinc protected steel frame.
  • Also available as a single door (specified separately), width 690 to 1290mm.
  • Double opening width 1290 to 2600mm.
  • Can be specified to the PAS24 standard, upon request.

General information

Color

Other

Guidance for specification option:

Available in 500 RAL and BS colours.

Finish

Powder-coated

Guidance for specification option:

Polyester powder-coated (PPC).

Material

Steel

Laminate

Guidance for specification option:

PVC laminate.

Shape

Rectangle

Length

Bespoke

Width

1290 mm

2600 mm

Manufacturer guidance

  • Double opening width 1290 to 2600 mm size range, consult manufacturer for details.
  • As drawing and schedule, insert details.

Height

2900 mm

Manufacturer guidance

  • Maximum height.
  • As drawing and schedule, insert details.

Warranty description

One year

Uniclass

Pr_30_59_24_52 Carbon steel doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

Product range

Armourdoor - Steel Doors

Specification data - Carbon steel doorsets

Configuration

Double leaf, single action.

Doorset size

-

Manufacturer guidance

Insert requirements:

  • Width: 1290–2600 mm.
  • Height (maximum): 2900 mm.

Performance

-

Intruder resistance

-

Minimum requirement

Not required.

To PAS 24.

Frame

-

Material

1.6 mm Zintec/ Aluzinc steel.

Threshold

15 mm rebated.

Guidance for specification option:

Standard.

12.5 mm 564A aluminium.

Guidance for specification option:

DDA compliant.

5 mm driveable.

Guidance for specification option:

DDA compliant.

Perimeter seals or inserts

Sub frame included to allow up to 30 mm tolerance for site installations.

Finish

-

Coating

Polyester powder-coated.

Guidance for specification option:

Standard range of RAL/ BS4800 colours.

Texture

Polyester powder-coated.

Wood-grain.

Colour

-

Manufacturer guidance

Insert requirement. Available in 500 RAL and BS4800 colours.

Installation fasteners

Fitted with dog bolt for hinge as standard.

Door leaf

-

Thickness

48 mm.

Core

Resin-impregnated honeycomb core.

Guidance for specification option:

Standard.

Mineral wool.

Timber.

Panel details

Fire Exit steel door AD10.

Material

1.2 mm-thick corrosion resistant Zintec/ Aluzinc steel.

Glazing

-

Type

-

Manufacturer guidance

Insert requirements.

Manifestation

-

Manufacturer guidance

Insert requirements.

Finish

-

Coating

PVC laminate.

Stainless steel.

Polyester powder-coated.

Texture

Smooth.

Guidance for specification option:

Polyester powder-coated, PVC laminate or stainless steel.

Wood grain.

Guidance for specification option:

Polyester powder-coated only.

External colour

Guidance for specification option:

Insert requirements; Available in 500 RAL and BS colours.

Internal colour

As External.

Guidance for specification option:

Insert requirements; Available in 500 RAL and BS colours.

Hardware

Rim panic latch, mortice panic night latch and two-point panic bolt.

Guidance for specification option:

Rim panic latch, mortice panic night latch and two-point panic bolt.

  • Rim panic latch: Surface mounted, single point rim panic latch.
  • Mortice panic night latch: Operated by an internal cross bar, providing medium security. Can be fitted with external cylinder for external access.
  • Two-point panic bolt: Surface mounted, two point bolting panic with full internal crossbar.

Double escape door: The combination of the panic latch on the active leaf and a bolt on the inactive one allows independent escape.

Accessories

None.

External cylinder.

Guidance for specification option:

For mortice panic night latch.

Operation

Manual.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Steel

Laminate

Guidance for specification option:

PVC laminate.

Recyclability

95

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

17 %
