The Armourdoor Fire Exit Steel Door AD10 is constructed from 1.2mm zinc protected steel sheets joined together in a bonding process with a choice of infill.
The Armourdoor Fire Exit Steel Door AD10 is constructed from 1.2mm zinc protected steel sheets joined together in a bonding process with a choice of infill. Choose from honeycomb core, rock wool, or solid timber dependant on insulation and security requirements.
The door is supported by a 1.6 mm profiled zinc protected steel frame.
Common Use: Commonly used as a fire exit door that is used by the general public. It provides safe and effective escape through the doorway with minimal effort and without prior knowledge of operation.
Single Double opening width from 1290 to 2800 mm.
Features | Steel fire exit door used by the general public to provide safe and effective escape with minimal effort without prior knowledge of operation |
Finish | Powder coated (optional: wood grain, PVC laminate and stainless steel) |
Size | Opening: 1290-2800 mm. Height: ≤ 2900 mm |
Uniclass 2015 |
Platform | Compatible | Version | Certified to |
---|---|---|---|
![]() | IFC2X3 | 1 | 1.3 |
![]() | Revit 2015 | 2 | 1.3 |
