Fields Security Doorset
Timber doorset.
Description
Door leaves are constructed from 54 mm high performance laminated, solid timber core and faced with MDF.
Features:
- Available fire rating FD30 or non-fire rated.
- Up to 30 dB.
- Sizes and features not covered by the current test evidence may be accommodated by commissioning a contract-specific assessment.
General information
Size | Insert requirements. |
Finish | Clear lacquer Factory painted Final finish Primed for onsite painting Stain |
Features | Available fire rating FD30 or non-fire rated Up to 30 dB Sizes and features not covered by the current test evidence may be accommodated by commissioning a contract-specific assessment |
Uniclass 2015 | |
CAWS | L20/410 Wood doorsets L20/420 Wood doorsets L20/430 Wood doorsets L20/55 Doorsets |
Specification data - Wood doorsets
Product Reference | Fields Security Doorset FD30Fields Security Doorset non-fire rated |
Size | Insert requirements. |
Facing | Hygienilac PVCAntibacterial facing. LaminateExposed, concealed over door edges. PVCExposed, concealed over door edges. Wood veneerBook, slip or random matched and laid either vertically or horizontally. |
Finish | Clear lacquerFactory paintedFinal finishPrimed for onsite paintingStainTinted lacquer |
Ironmongery | Insert requirements. |
Standard product features | Size (maximum): 2290 x 922 mm. Thickness: 54 mm. |
Product Options | Performance:
Lipping: All doors will be supplied with hardwood lippings, concealed or exposed and square or rebated. Frame and architraves: Supplied with a 640 kg/m³ density or greater hardwood of minimum section 94 x 57 mm. Ironmongery: Tested with the following ironmongery:
|
