FFB-ES Plus FireStop Sealant - Elastomeric Fire Resistant Sealant
Verified by manufacturer 9 days ago
White (569303)
White (569303)
One-part water-based acrylic spray which has been designed to provide smoke and fire protection on horizontal construction joints, vertical penetrations and curtain wall perimeter joints.
Application
Horizontal linear joints; perimeter joint seals; cable trays. Internal applications.
Building materials:
- Rigid wall and floor construction;
- Masonry;
- Concrete;
- Aerated concrete.
Description
One-part water-based acrylic spray which has been designed to provide smoke and fire protection on horizontal construction joints, vertical penetrations and perimeter joints.
Features and benefits:
- Tested in accordance with EN 1366-3, EN 1366-4, EN 1364-4, ASTM E1966 (UL 2079) the FFB-ES Plus is certified by ETA, UL-EU and UL-US.
- Excellent movement capabilities.
- Applied together with stone wool backing it provides up to four hours' fire rating.
- 1.6 mm WFT required.
- Acoustic properties.
- Water permeability.
- Low VOC, halogen and solvent free.
- Spray or brush applied.
- Air permeability.
- Paintable.
General information
Color | White Red |
Finish | Smooth |
Material | Acrylic |
Shape | Formless |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | P12/47 Sealants P12/390 Sealants |
SKU Code | 569303, 569304 |
Specification data - Acrylic construction joint sealants
Third-party certification | UL-EU certificate UL-EU-01276-EN. European Technical Assessment ETA-23/0166 and ETA-23/0164. Environmental Product Declaration EPD-DBC-FIW-20230413-IBF1-EN. CE marking 0800-CPR-III-1170-4, 0800-CPR-III-1170-6. |
Sealant type | One-part water-based spray. |
Colour | White. |
Fire performance | |
Fire resistance | To EN 1366-3, EN 1364-4, ASTM-E 1966 (UL 2079). Guidance for specification option: Consult manufacturer for details. |
Reaction to fire | To EN 13501-1, Class D-s1, d1. To ASTM E84, Class A. |
Curing time | Curing rate approx. 1 mm per 24 hours. |
Acoustic performance | Rw (C;Ctr) = 44 (-4;-9) dB. |
Technical characteristics, other | Movement capability: ≤25% according to EN 1366-4, EN 1364-4/ UL 2079: Cycling 500 times, 15% movement as of ASTM E 1399 (Class II and III). |
Application thickness | Coating: 1.6 mm nominal, wet film thickness (dependent on application). Guidance for specification option: Yield varies by application. |
Shelf life | 18 months. |
pH value | 7.8–8.8. |
Air permeability | No measurable air flow, positive and negative pressure tested to EN 1027. |
Water permeability | No water penetration at up to 600 Pa tested to EN 1027. |
Sustainability data
Material | Acrylic |
A1-A3 (production stage) | Embodied carbon as defined in BS EN 15804 |
Normalised unit | 1.3 kg CO₂ eq/kg |
Declared unit | 1.32 kg CO₂ eq/kg Self-declared |
Literature
FireBarrier ElastoSeal Plus FFB-ES Plus - Datasheet
eurofins VOC Emission Test Report - Indoor Air Comfort GOLD - Fischer FFB-ES Plus
