Ezy-Install® Magnetically Receptive Underlay

Verified by manufacturer 5 months ago

Circular Building Solutions (CBS)

High performance magnetically receptive acoustic rubber underlay for adhesive-free flooring installation.

Jump to:
+44 (0) 7703 132494 Website

Application

Suitable for residential and commercial flooring installation. For use with:

  • Magnetically backed floor coverings including Luxury Vinyl Tile (LVT), magnetic wood and ceramics.
  • Standard carpet tiles, woven vinyl tiles and Luxury Vinyl Tiles which are ≥4 mm thick can be installed on the system using IOBAC MagTabs™.

Description

Roll down flooring system made up from acoustic black rubber crumb pad, non-woven polypropylene scrim and a dual-grip metallised resin coating.


For use with:

  • Magnetically backed floor coverings including Luxury Vinyl Tile (LVT), magnetic wood and ceramics.
  • Standard carpet tiles, woven vinyl tiles and Luxury Vinyl Tiles which are ≥4 mm thick can be installed on the system using IOBAC MagTabs™.


Features and benefits:


Clean removal

  • Floor tiles can be removed with no adhesive contamination and can be easily re-used or recycled
  • Ezy-Install Underlay left clean and ready for next flooring installation

Maximum grip

  • Distinctive dual-grip technology combines dry-tack and magnetism to provide secure hold to floor covering

Fast installation

  • Simply roll out and cut Ezy-Install to fit, then install floor covering on top
  • Often possible to go straight over existing flooring with no uplift required

Flexible designs

  • Compatible with a range of floor coverings - magnetic wood, Luxury Vinyl Tile (LVT), carpet, timber, ceramic
  • Install and switch flooring effortlessly for speedy design changes, access and repairs


Acoustic rubber crumb pad composed of a minimum of 80% recycled rubber tyres offers acoustic and underfoot comfort.


VOC-free, odourless plant-based polyurethane resin manufactured mostly from renewable castor oil.

General information

Color

Black

Material

Rubber

Guidance for specification option:

Black rubber crumb pad (composed of 80% recycled tyres).

Polypropylene

Guidance for specification option:

Non-woven polypropylene scrim (synthetic latex bonding agent).

Polyurethane

Guidance for specification option:

VOC-free, odourless plant-based polyurethane dual-grip resin coating.

Length

5000 mm

Width

1000 mm

Height

3 mm

Uniclass

Pr_35_57_11_74 Rubber crumb underlaysPrimary

CAWS

M42/10 Wood flooring

M42/110 Wood block flooring

K21/10 Wood laminate flooring

K21/115 Wood laminate flooring

M40/110 Tiling to

M50/130 Carpet tiling

M50/110 Resilient floor tiling

M40/5 Tiling to

M50/15 Carpet tiling

M50/10 Resilient floor tiling

Specification data - Rubber crumb underlays

Standards

To BS EN 14499.

Thickness (minimum)

3.0 mm.

Manufacturer guidance

Nominal thickness.

Recycled content

80% (minimum).

Guidance for specification option:

Acoustic rubber crumb pad.

Dynamic loading

To BS EN 14499:2015, 8% (after 1000 impacts).

Guidance for specification option:

To BS EN 14499:2015:

  • Compression after dynamic loading: 0.5 mm.
  • Work of compression after dynamic loading: 19 J/m².
  • Retention of original work of compression: 97.2%.

Loading

To BS EN 14499:2015, 4.20% (1 hour); 3.60% (24 hours).

Manufacturer guidance

Static loading: recovery period.

Water vapour transmission

To EN ISO 15106, 0.09 g/m²/day.

Manufacturer guidance

Water vapour transmission rate.

Water vapour resistance

To EN ISO 15106, 2887 MNs/g.

Acoustic performance

To BS EN ISO 10140-3: 2010 and BS EN ISO 717-2: 2013, measured improvement of impact sound, 17 dB; To ASTM – E492-09,
E989-06 and E2179-03, impact insulation class, IIC 49.

Roll size

1000 x 5000 mm.

Guidance for specification option:

5 m²/ roll.

Roll weight

14 kg.

Accessories

Not required.

IOBAC MagTabs™.

Guidance for specification option:

For standard tiles and ≥4 mm thick vinyl tiles. Specified separately.

Sustainability data

Contains Red List materials

No

Material

Rubber

Guidance for specification option:

Black rubber crumb pad (composed of 80% recycled tyres).

Polypropylene

Guidance for specification option:

Non-woven polypropylene scrim (synthetic latex bonding agent).

Polyurethane

Guidance for specification option:

VOC-free, odourless plant-based polyurethane dual-grip resin coating.
