Evolution - Structural

Verified by manufacturer 5 months ago

CEMEX UK

Evolution Structural is a self compacting concrete with low viscosity and free flowing characteristics designed for pouring into walls, columns, beams and precast applications.

Jump to:
BOS
+44 (0)800 667827 Website

Application

  • Columns.
  • Suspended floors.
  • Walls.
  • Basements.
  • Cores.
  • Precast.
  • Beams.

Description

A self-compacting concrete with low viscosity and free flowing characteristics designed for pouring into walls, columns, beams and precast applications. It sets with a smooth surface that needs no vibrating and no further finishing. It is a very attractive solution for any work above ground level or in precast factories.


Features and benefits:

  • Easily placed and economical.
  • Can generally be poured from a single discharge point.
  • Self-levelling and needs no compacting.
  • Reduced labour required for placing.
  • Sets with a smooth surface that requires minimal further finishing.
  • Enhanced workability and excellent strength characteristics.
  • No vibration necessary.
  • Reduced noise and health and safety issues.
  • Meets or exceeds the relevant British and European Standards.

General information

Color

Grey

Material

Concrete

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_20_31_16_21 Designated concretePrimary

CAWS

E10/105 Designated concrete

E10/132 Designed concrete

E10/20 Designated concrete

Specification data - Designated concrete

Properties

-

Consistence class

SF2.

Flowrate

SF2+/VS1 or VS2, medium/ high consistence 700–750 (± 50 mm).

Category

C50/60.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

3

Revit
-

4
